Maintenance
WARNING
Ifanextensioncordispluggedintotheappliance,
someonecouldaccidentallyoperateitwhileyou
areperformingmaintenanceonit,causingserious
personalinjury.
Disconnecttheextensioncordbeforeyouperformany
maintenance.
ReplacingtheRotor
1.Usea9/16-inchwrenchtoremovetheboltonthesideof
thehousing.
g001333
Figure7
2.Removetheoldrotorfromthehousing.
g001334
Figure8
3.Installthenewrotorinthehousingbyinsertingtheendof
therotorontothettedendinthehousingandrotatingthe
rotoruntilitsnapsintoposition.
g001344
Figure9
Note:Thehousingwillexwhenyouinstalltherotor.
4.Tightentheboltonthesideofthehousing.
g001333
Figure10
LubricatingthePower
Shovel
™
ThePowerShovel
™
doesnotneedlubrication;allbearingsare
lubricatedatthefactoryforthelifeoftheappliance.
Service
Tobestprotectyourinvestmentandmaintainoptimalperformance
ofyourT oroequipment,countonT orogenuineparts.Whenit
comestoreliability,T orodeliversreplacementpartsdesignedto
theexactengineeringspecicationsofourequipment.Forpeace
ofmind,insistonT orogenuineparts.
Double-insulated
Appliances
Inadouble-insulatedappliance,twosystemsofinsulation
areprovidedinsteadofgrounding.Nogroundingmeansis
providedonadouble-insulatedappliance,norshouldameansfor
groundingbeaddedtotheappliance.Servicingadouble-insulated
appliancerequiresextremecareandknowledgeofthesystem,
andshouldbedoneonlybythequaliedservicepersonnel
atyourAuthorizedServiceDealer.Replacementpartsfora
double-insulatedappliancemustbeidenticaltothepartsthey
replace.Adouble-insulatedapplianceismarkedwiththewords
“DoubleInsulation”or“DoubleInsulated.”Thesymbol(square
withinasquare)
mayalsobemarkedontheappliance.
ProductInformation
Amodelandserialnumberdecalislocatedonthehousing.
Alwaysrefertospecicnumbersonthedecalincorrespondence
orwhenyouneedreplacementparts.
