g194423
Figure4
1.Chargerventingareas
3.Rightindicatorlight
2.Leftindicatorlight
5.T oremovethebatterypack,slidethebattery
backwardoutofthecharger.
6.RefertothefollowingtabletointerprettheLED
indicatorsonthebatterycharger.
LeftLight
RightLight
Indicates:
Off
Red
Chargerison;nobattery
packinserted
RedRedBatterypackischarging
Green
RedBatterypackischarged
Orange
RedBatterypackistoowarm
RedBlinkingRedReplacethebatterypack
InstallingtheBatteryPack
Important:Operatethebatterypackonlyin
temperaturesthatarewithintheappropriate
range;refertoSpecications(page5).
1.Makesurethattheventsonthebatteryareclear
ofanydustanddebris.
2.Lineupthecavityinthebatterypackwiththe
tongueonthetool.
3.Graspthetriggerhandle.
4.Slidethebatterypackintothetooluntilthe
batterylocksintothelatch(Figure5).
g189881
Figure5
(Trimmershown)
1.Batterylatch
RemovingtheBatteryPack
Pressthebatterylatchonthetooltoreleasethe
batterypackandslidethebatterypackoutofthetool
(Figure6).
g192774
Figure6
(Trimmershown)
1.Batterylatch
