AdjustingtheSelf-PropelDrive
Wheneveryouinstallanewself-propelcableorifthe
self-propeldriveisoutofadjustment,adjusttheself-propel
drive.
1.Turntheadjustmentknobcounterclockwisetoloosen
thecableadjustment(Figure28).
g027709
Figure28
1.Handle(leftside)3.Self-propel-drivecable
2.Adjustmentknob
2.Adjustthetensiononthecable(Figure28)bypullingit
backorpushingitforwardandholdingthatposition.
Note:Pushthecabletowardtheenginetoincrease
thetraction;pullthecableawayfromtheengineto
decreasethetraction.
3.Turntheadjustmentknobclockwisetotightenthe
cableadjustment.
Note:Tightentheknobrmlybyhand.
CleaningtheMachine
ServiceInterval:Beforeeachuseordaily
WARNING
Themachinemaydislodgematerialfromunderthe
machine.
•Weareyeprotection.
•Stayintheoperatingposition(behindthe
handle)whentheengineisrunning.
•Donotallowbystandersinthearea.
CleaningtheMachineUsingthe
WashoutPort
Forbestresults,cleanthemachinesoonafteryouhave
completedmowing.
1.Lowerthemachinetoitslowestcutting-heightsetting.
RefertoAdjustingtheCuttingHeight(page9).
2.Movethemachineontoaatpavedsurface.
3.Washouttheareaunderthereardeectorwherethe
clippingsgofromtheundersideofthemachinetothe
grassbag.
4.Attachagardenhosethatisconnectedtoawater
supplytothewashoutport(Figure29).
Figure29
1.Washoutport
5.Turnthewateron.
6.Starttheengineandrunituntiltherearenomore
clippingsthatcomeoutfromunderthemachine.
7.Stoptheengine.
8.Shutoffthewateranddisconnectthegardenhose
fromthemachine.
9.Starttheengineandrunitforafewminutestodrythe
undersideofthemachinetopreventitfromrusting.
10.Allowtheenginetocoolbeforestoringthemachine
inanenclosedarea.
CleaningtheMachineinthe
Vertical-stowPosition
1.Setthemachineinthevertical-stowposition;referto
StoringtheMachineintheVertical-StowPosition(page
12).
2.Washouttheclippingsfromunderthemachine.
17

Toro Recycler 20339 Specifications

General

Mulching Capability	Yes
Bagging Capability	Yes
Side Discharge Capability	Yes
Starter Type	Recoil
Deck Material	Steel
Engine	Briggs & Stratton
Cutting Width	22 inches
Cutting Height	1.0 to 4.0 inches
Fuel Tank Capacity	0.25 gallons
Wheel Size	Front 8 inches, Rear 11 inches
