4
General Specifications (continued)
General Specifications
(approx.)
Width
41–1/2” (1.054 m) with iron wheels, 45” (1. 1 43 m) with semi–pneumatic tires.
Height
16” (0.406 m) or 18” (0.457 m) depending on tires.
Weight
11 Blade – 252 lbs. (114 kg)
7 Blade – 248 lbs. (112 kg)
5 Blade – 243 lbs. (110 kg)
All with 16” (0.406 m) semi–pneumatic tires (without draw bars).
Note: Specifications and design subject to change without notice.
Optional Equipment
16” (0.406 m) cast iron wheel Model No. 01336
16” (0.406 m) pneumatic tires Model No. 01323
16” (0.406 m) semi–pneumatic low
profile
Model No. 01304
18” (0.457 m) semi–pneumatic
tires
Model No. 01035
Roller Scraper Kit Part No. 47–4540
Grass Dispersion Shield Kit
(5 & 7 Blade)
Part No. 51–0800
Grass Dispersion Shield Kit
(11 Blade)
Part No. 47–5390
Adapter Kit Model No. 01050
Universal Frame Adapter Kit Part No. 47–2220
To Next Page
