ProductOverview
g205066
Figure3
1.Throttlelever
8.Cuttingwheel
2.Hourmeter9.Beltcover
3.Cycloneairlter
10.Lifthandle
4.Chokelever
11.Fuelcap
5.Fuelvalve12.Parkingbrake
6.Sedimentcup13.Safetybail
7.Starter
14.Handle
Controls
Becomefamiliarwithallthecontrols(Figure3)before
youstarttheengineandoperatethemachine.
SafetyBail
Thesafetybailcontrolstheengine.Holdthesafety
bailagainstthehandlewhenyoustarttheengineand
usethemachine.Releasethesafetybailtoshutoff
theengine(Figure3).
ThrottleLever
Thethrottlelevercontrolsenginespeed.Withthe
leverdown,intheDISENGAGEposition,theengine
runsatidle.Thisisalsothestartingposition.When
theenginespeedincreases,totheENGAGEDposition,
thecentrifugalclutchengagesandthecuttingwheel
rotates.
g014499
Figure4
1.Throttle—Disengage
position
2.Throttle—Engaged
position
ParkingBrake
Theparkingbrakeholdstheleftwheelfromturningto
securethemachineandforeasymovementofthe
machinefromsidetosidewhengrindingastump
(Figure5).
g205069
Figure5
1.Parkingbrake(engaged)
2.Parkingbrake
(disengaged)
HourMeter
Thehourmeterdisplaysthenumberofhoursof
operationthathavebeenloggedonthemachine.
ChokeLever
Usethechokelever(Figure3)tostartacoldengine.
Beforepullingtherecoil-starthandle,movethechoke
levertotheCLOSEDposition.Oncetheengineis
running,movethechokelevertotheOPENposition.
Donotusethechokeiftheengineisalreadywarmed
uporiftheairtemperatureishigh.
