Upon power-up, the controller will display:
The TDC-100/200 will initiate a diagnostic test automatically during power-up. This function will take approximately
ten seconds and it can not be bypassed. If a problem is detected during the diagnostic test, it will be indicated on the
display.
When completed, information will be displayed momentarily on the screen for five seconds. This status information
can not be edited. The information is as follows:
Line 1: TDC-100/200 Firmware Version and Revision Date
Line 2: Detect: [xx stations, yy sensors] (xx = number of stations detected, yy = number of sensors detected)
Line 3: Last Power Downtime Date and Time
Example:
The default Home display will follow after the diagnostic display has timed-out.
Home display example:
Pressing the Home Key will revert to the default display. When editing irrigation programs, Station or System
settings, pressing the Home Key will save any setting modifications and return the user to the Home display.
Home display example:
The Day Change line will display the next program start time (Next Start: HH:MM) if the current day is an active
watering day. If the controller is running a program, the Day Change line will display Running XX programs to
indicate the number of active programs.
The following example display has two programs running with two stations manually activated, the display will read:
(The “%” symbol before the runtime indicates that station 1 is percent adjusted.)
(P01 indicates Program 01 is currently active)
(The “D” symbol after the station number indicates that station 3 is disabled.)
(The “P” symbol after the station number indicates that program 02 is paused.)
(“Man” indicates Manual Watering is currently active)
(The “S” symbol after the station number indicates that program 02 is stacked.)
Note: Program stacking occurs when the controller is running a program where the maximum simultaneous station
limit is surpassed. Additional scheduled programs will be stacked (delayed) until an available station can be activated.
Mon 08/07/06 11:15am
Sec: 50
Rain
Day Change: 12:00am
Home Key
Power-Up Diagnostics
77
TDC–100/200 System
Booting
Rev: D1.21, 04/25/06
Detect:200sta, 00sen
PD 05/24/06 10:51:20
Mon 08/07/06 10:50am
Sec: 45
Day Change: 12:00am
Mon 08/07/06 10:50am
Sec: 45
Day Change: 12:00am
Wed 08/09/06 06:50am
Sec: 32
Running 02 Programs
P01 Sta01 %00:05:00
P01 Sta02 00:05:00
P01 Sta03D 00:05:00
P02 Sta10P 00:10:00
Man Sta18S 00:05:00
Man Sta19S 00:10:00
Rain detected indicator for rain sensor
equipped Decoder systems
