PushingtheMachineby
Hand
Important:Alwayspushthemachinebyhand.
Donottowthemachine,becausetowingmay
damageit.
Thismachinehasanelectric-brakemechanism,
andtopushthemachine,thekeymustbeinthe
RUNposition.Thebatteryneedstobechargedand
functioningtodisengagetheelectricbrake.
PushingtheMachine
1.Parkthemachineonalevelsurface,disengage
theblade-controlswitch,andmovethe
motion-controlleversoutwardtothePARK
position.
2.Shutofftheengine,removethekey,andwait
forallmovingpartstostopbeforeleavingthe
operatingposition.
3.Locatethebypassleversontheframeonboth
sidesoftheengine.
4.Movethebypassleversforwardthroughthekey
holeanddowntolocktheminplace(Figure29).
Note:Dothisforeachlever.
WARNING
Contactwithhotsurfacesmaycause
personalinjury.
Keepyourhands,feet,face,clothing
andotherbodypartsawaytheengine,
muferandotherhotsurfaces.
5.Turntheignitionkeyonanddisengagethe
parkingbrakebymoving1motion-controllever
outofthePARKposition.
Note:Donotstartthemachine.
g295542
Figure29
1.Bypass-leverlocations
3.Leverpositionforpushing
themachine
2.Leverpositionfor
operatingthemachine
6.Whennished,ensurethatthekeyhasbeen
returnedtotheSTOPpositiontoavoiddraining
thebatterycharge.
7.Movethemotion-controlleversoutwardtothe
PARKposition.
OperatingtheMachine
Movethebypassleversrearwardthroughthekeyhole
anddowntolocktheminplaceasshowninFigure29.
Note:Dothisforeachlever.
