g028025
Figure26
AdjustingtheAnti-Scalp
Rollers
Machineswitha107cm(42inch),
127cm(50inch),or137cm(54
inch)MowerDeckOnly
Wheneveryouchangetheheightofcut,adjustthe
heightoftheanti-scalprollers.
Note:Adjusttheanti-scalprollerssothattherollers
donottouchthegroundinnormal,atmowingareas.
1.Disengagetheblade-controlswitch(PTO),move
themotion-controlleverstotheNEUTRAL-LOCK
position,andengagetheparkingbrake.
2.Shutofftheengine,removethekey,andwait
forallmovingpartstostopbeforeleavingthe
operatingposition.
3.Adjusttheanti-scalprollersasshowninFigure
27tomatchtheclosestheight-of-cutposition.
g010233
Figure27
1.Anti-scalproller3.Flangenut
2.Bolt4.Holespacing
Machineswitha152cm(60inch)
MowerDeckOnly
Wheneveryouchangetheheightofcut,itis
recommendedtoadjusttheheightoftheanti-scalp
rollers.
1.Disengagetheblade-controlswitch(PTO),move
themotion-controlleverstotheNEUTRAL-LOCK
position,andengagetheparkingbrake.
2.Shutofftheengine,removethekey,andwait
forallmovingpartstostopbeforeleavingthe
operatingposition.
3.Removetheangenut,anti-scalproller,andbolt
fromthebracket(Figure28).
Note:Keeptheboltandanti-scalproller
togetherwhenremoving.
g024312
Figure28
1.Flangenut4.Bushing
2.Spacer
5.Bolt
3.Anti-scalproller
4.Aligntheboltandanti-scalprollerinthe
holeofthebracketthatmatchedtheclosest
height-of-cutposition(Figure28).
28
