Toro TimeCutter SS 4216 74616 User Manual

121-0771
1.Choke4.Slow
2.Fast
5.Powertake-off(PTO),Bladecontrolswitch
3.Continuousvariablesetting
ProductOverview
Figure4
1.Deector6.Operatorseat
2.Reardrivewheel7.Fueltankcap
3.Controlpanel8.Smartspeedlever
4.Motioncontrollevers9.Footrest
5.Heightofcutlever
10.Frontcasterwheel
Controls
BecomefamiliarwithallofthecontrolsinFigure4and
Figure5beforeyoustarttheengineandoperatethemachine.
Figure5
ControlPanel
1.Throttle/Choke
3.Bladecontrolswitch
(powertake-off)
2.Ignitionswitch
IgnitionSwitch
Theignitionswitchhasthreepositions,Off,RunandStart.
ThekeywillturntoStartandmovebacktoRunuponrelease.
TurningthekeytotheOffpositionwillstoptheengine;
however,alwaysremovethekeywhenleavingthemachine
topreventsomeonefromaccidentallystartingtheengine
(
Figure5).
Throttle/ChokeControl
Thethrottleandchokeiscombinedintoonecontrollever.
Thethrottlecontrolstheenginespeedandithasacontinuous
variablesettingfromSlowtoFast.Engagethechokeby
movingtheleverpasttheFastsettinguntilitstops(
Figure5).
11
