Toro TRX-16 User Manual

RemovingtheBottom
Shield
1.Parkthemachineonalevelsurface,engage
theparkingbrake(ifapplicable),andlowerthe
hydrauliclift.
2.Shutofftheengineandremovethekey.
3.Loosenthe2boltssecuringthebottomshield
sequentiallyuntiltheshieldisfree(Figure22).
g011472
Figure22
1.Bottomshield2.Bolts
4.Pulltheshieldbackandoutofthemachine.
5.Toinstalltheshieldbeforeoperatingthe
machine,slidethebottomshieldintothe
machinesothatitrestsonall4tabsandsecure
itwiththe2boltsyouloosenedpreviously
(Figure22).
Note:Youmayneedtoliftuponthebottom
shieldtoensurethatitrestsonthefronttabs.
Lubrication
GreasingtheMachine
ServiceInterval:Beforeeachuseordaily(Grease
immediatelyaftereverywashing.)
GreaseType:General-purposegrease.
1.Parkthemachineonalevelsurface,engagethe
parkingbrake,andlowerthehydrauliclift.
2.Shutofftheengineandremovethekey.
3.Cleanthegreasettingswitharag.
4.Connectagreaseguntoeachtting(Figure23
throughFigure26).
5.Pumpgreaseintothettingsuntilgreasebegins
tooozeoutofthebearings(approximately3
pumps).
6.Wipeupanyexcessgrease.
g007821
Figure23
g007822
Figure24
23
