Toro Wheel Horse XL 380H User Manual

InstallingtheMower
Withoutthegrassdeector,dischargecover,
orcompletegrasscatcherassemblymounted
inplace,youandothersareexposedtoblade
contactandthrowndebris.Contactwiththe
rotatingmowerblade(s)andthrowndebriswill
causeinjuryordeath.
•Neverremovethegrassdeectorfrom
themowerbecausethegrassdeector
routesmaterialdowntowardtheturf.Ifthe
grassdeectoriseverdamaged,replaceit
immediately.
•Neverputyourhandsorfeetunderthe
mower.
•Nevertrytoclearthedischargeareaor
mowerbladesunlessyoumovethepower
takeoff(PTO)toOffandrotatetheignition
keytoOff.Alsoremovethekeyandpullthe
wireoffthesparkplug(s).
1.Parkthemachineonalevelsurface.
2.Disengagethebladecontrol(PTO).
3.Settheparkingbrake.
4.Stoptheengine,waitforallmovingpartstostop,and
removethekeybeforeleavingtheoperatingposition.
5.Turnthefrontwheelsfullytotheleft.Slidethe
mowerunderthechassisfromtherightside.
6.Installthemowerbeltontothelowerenginepulley
(Figure41).
7.Installthemowerpivotmountbracketsontothe
frontaxlewiththeboltsandlocknuts(Figure42).
Figure42
1.Pivotmountbracket3.Locknut
2.Bolt(5/16x2-1/2inch)
8.Movetheheight-of-cutleverintotheDnotch.
9.Removetheliftassistspringbetweenthemowerright
sideliftbracketandtheretainingbolt(Figure43).
Figure43
1.Spring3.Springtool
2.Bolt
Note:Usethespringtoolprovidedwiththe
machine.
10.Movetheheight-of-cutleverintotheAnotch.
11.Slidetheendofthelongrodthroughtheholeinthe
mowermount(Figure44).
Figure44
1.Hairpincotterandthick
washer
4.Mowermount
2.Longrod5.Hairpincotterandthin
washer
3.Levelingbracket
12.Installthethinwasherandhairpincottertosecure
therodinplace(Figure44).
13.Mounttheslottedmowerlevelingbracketontothe
pinonthemowermount(Figure44).
14.Installthethickwasherandhairpincottertosecure
themower(Figure44).
15.Repeat11through14ontheoppositesideofthe
mower.
16.Hooktheidlerspringfromtheidlerpulleyarmto
theeye–boltonthemower(Figure45).
31
