g017417
2
Figure83
1.Removethereardeckliftattachmentshoulderboltandnut.
2.Removethefrontdeckliftattachmentshoulderboltandnut.
8.Slidethedeckouttotherightsideofthemachine.
ReplacingtheGrassDeector
WARNING
Anuncovereddischargeopeningcouldallowthe
lawnmowertothrowobjectsintheoperator'sor
bystander'sdirectionandresultinseriousinjury.
Also,contactwiththebladecouldoccur.
Neveroperatethelawnmowerunlessyouinstalla
coverplate,amulchplate,grassdeectororbagger.
1.Removethelocknut,bolt,springandspacerholding
thedeectortothepivotbrackets(Figure84).
Removedamagedorworngrassdeector.
g015594
1
6 2
4
7
3
5
Figure84
1.Bolt
5.Springinstalled
2.Spacer6.GrassDeector
3.Locknut
7.Jhookendofspring
4.Spring
2.Placespacerandspringontograssdeector.Place
oneJendofspringbehinddeckedge.
Note:MakesureoneJendofspringisinstalled
behinddeckedgebeforeinstallingtheboltasshown
in
Figure84.
3.Installboltandnut.PlaceoneJhookendofspring
aroundgrassdeector(Figure84).
Important:Thegrassdeectormustbeable
torotate.Liftthedeectoruptothefullopen
positionandensurethatitrotatesintothefull
downposition.
