Toro Z Master Professional 5000 Series User Manual

g192516
Figure46
MachinewithRearDischargeShown
4.Greasethedrive-beltidlerarms(Figure47).
g009030
Figure47
5.Greasethedeck-beltidlerarms(reardischarge
machinesonly)asshowninFigure48.
g024207
Figure48
MachineswithRearDischargeOnly
6.Removethedustcapandadjustthecaster
pivots.
Note:Keepthedustcapoffuntilgreasingis
done.
7.Removethehexplug.
8.Threadagreasettingintothehole.
9.Pumpgreaseintothettinguntilitoozesout
aroundthetopbearing.
10.Removethegreasettinginthehole.
11.Installthehexpluganddustcap(Figure49).
g027339
Figure49
12.Greasethecaster-wheelbearings(Figure49).
42
