ELECTRICAL REPLACEMENT PARTS LIST

Location No. TSB P/N Reference No. Description

RESISTORS

! R402 BZ210021 R65582680J R,FUSE 68 OHM 1/2W

! R410 BZ210087 R3X18A221J R,METAL OXIDE 220 OHM 2W

! R426 BZ210030 R4X5T4472F R,METAL 4.7K OHM 1/4W

! R436 BZ210023 R4X5T4183F R,METAL 18K OHM 1/4W

! R438 BZ210232 R6558A6R8J R,FUSE 6.8 OHM 2W

! R439 BZ210003 R3K181102J R,METAL 1K OHM 1W

! R441 AD300037 R4X5T6153F R,METAL 15K OHM 1/6W

! R452 AD301143 R3X181R27J R,METAL OXIDE 0.27 OHM 1W

! R500 BZ210080 R0G3K2275K RC 2.7M OHM 1/2W

! R501 AD301596 R5X2AE010J R,CEMENT 1 OHM 7W

! R502 AD301016 R3X28A331J R,METAL OXIDE 330 OHM 2W

! R506 BZ210162 R002T4682J RC 6.8K OHM 1/4W

! R517 BZ210191 R3X28B010J R,METAL 1 OHM 3W

! R520 BZ210206 R002T2155J RC 1.5M OHM 1/2W

! R527 BZ210149 R3X18AR68J R,METAL OXIDE 0.68 OHM 2W

! R541 BZ210190 R63581R22J R,FUSE 0.22 OHM 1W

! R542 BZ210063 R3X181R22J R,METAL OXIDE 0.22 OHM 1W

! R602 AD301975 R3X28B120J R,METAL OXIDE 12 OHM 3W

! R649 AD302271 R3X28B5R6J R,METAL OXIDE 5.6 OHM 3W

! R803 BZ210026 R3X18A153J R,METAL OXIDE 15K OHM 2W

! R805 BZ210026 R3X18A153J R,METAL OXIDE 15K OHM 2W

! R807 BZ210026 R3X18A153J R,METAL OXIDE 15K OHM 2W

CAPACITORS

C147 AE000565 CS0RCH4L1J CC 33 PF 50V CH

C148 AE000565 CS0RCH4L1J CC 33 PF 50V CH

C149 AE000565 CS0RCH4L1J CC 33 PF 50V CH

C408 BZ110032 E5EZF3102M CE 1000 UF 25V

C412 AD301318 P4N8FJ471J CMPP 470 PF 1.25KV

! C413 AD301977 E0ELF4102M CE 1000 UF 35V

C418 AD301144 P4J7F3274J CMPP 0.27 UF 250V PMS

! C420 BZ110218 P4N8FJ103H CMPP 0.01 UF 1.25KV

C425 BZ110202 C0PLRR713K CC 0.001 UF 2KV R

! C426 AD300061 E5EZFD220M CE 22 UF 250V

! C430 BZ110195 E02LU8220M CE 22 UF 100V

! C501 BZ110053 E02LF3102M CE 1000 UF 25V

C502 BZ110202 C0PLRR713K CC 0.001 UF 2KV R

C503 BZ110202 C0PLRR713K CC 0.001 UF 2KV R

! C504 AD301729 E02LU52R2M CE 2.2 UF 50V

! C505 BZ110025 P2122B224M CMP 0.22 UF 275V ECQUL

! C506 BZ110035 P2122B104M CMP 0.1 UF 275V ECQUL

! C507 AD301635 E51CGC331M CE 330 UF 200V

! C508 AD301108 CD39E0MH3M CC 0.0022UF 250V

! C513 AD301026 CD39E0M13M CC 0.001 UF 250V

C517 BZ110191 C03L0R7E3K CC 0.0015UF 2KV R

! C519 AD301026 CD39E0M13M CC 0.001 UF 250V

! C521 AD300060 E62NFB101M CE 100 UF 160V

! C527 BZ110119 E02LF2222M CE 2200 UF 16V

C535 BZ110202 C0PLRR713K CC 0.001 UF 2KV R

C639 AD301321 CQG0CH412J CC 100 PF 50V CH

C646 AD301321 CQG0CH412J CC 100 PF 50V CH

C647 AD301321 CQG0CH412J CC 100 PF 50V CH

C802 AD300078 C0JBB0713K CC 0.001 UF 2KV B

C1003 BZ110053 E02LF3102M CE 1000 UF 25V

C1004 BZ110053 E02LF3102M CE 1000 UF 25V

C1009 BZ110053 E02LF3102M CE 1000 UF 25V

DIODES

D001 BZ410037 D97U03301B DIODE,ZENER MTZJ33B T-77

D104 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77

D105 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77

D106 BZ410020 D97U05R11B DIODE,ZENER MTZJ5.1B T-77

D109 BZ410054 0021721150 LED SLR-342VCT32

D113 BZ410021 D97U05R61B DIODE,ZENER MTZJ5.6B T-77

D402 BZ410043 D2WT011E10 DIODE,SILICON 11E1-EIC

D403 BZ410019 D97U03001B DIODE,ZENER MTZJ30B T-77

D404 BZ410020 D97U05R11B DIODE,ZENER MTZJ5.1B T-77

! D405 BZ410063 D2WTAU02A0 DIODE,SILICON AU02A-EIC

! D406 BZ410021 D97U05R61B DIODE,ZENER MTZJ5.6B T-77

! D407 BZ410063 D2WTAU02A0 DIODE,SILICON AU02A-EIC

D410 BZ410019 D97U03001B DIODE,ZENER MTZJ30B T-77

! D411 BZ410063 D2WTAU02A0 DIODE,SILICON AU02A-EIC

D414 BZ410043 D2WT011E10 DIODE,SILICON 11E1-EIC
