ELECTRICAL REPLACEMENT PARTS LIST
REF. NO. PART NO. DESCRIPTION REF. NO. PART NO. DESCRIPTION
RESISTORS RESISTORS
R001 R002T2183J RC 18K OHM 1/2W ! R501 R5X2CD5R6J R,CEMENT 5.6 OHM 5W
R002 R002T2183J RC 18K OHM 1/2W ! R502 R002T2155J RC 1.5M OHM 1/2W
R003 R002T4271J RC 270 OHM 1/4W ! R503 R3X18A1R2J R,METAL OXIDE 1.2 OHM 2W
R004 R002T4271J RC 270 OHM 1/4W R504 R801R7562J RC 5.6K OHM 1/10W
R005 R801R7124J RC 120K OHM 1/10W R506 R002T4223J RC 22K OHM 1/4W
R006 R801R7472J RC 4.7K OHM 1/10W R507 R801R7222J RC 2.2K OHM 1/10W
R007 R801R7750J RC 75 OHM 1/10W R508 R801R7103J RC 10K OHM 1/10W
R102 R801R7222J RC 2.2K OHM 1/10W ! R509 R63581R22J R,FUSE 0.22 OHM 1W
R104 R801R7821J RC 820 OHM 1/10W R510 R002T4824J RC 820K OHM 1/4W
R105 R801R7103J RC 10K OHM 1/10W R511 R002T2470J RC 47 OHM 1/2W
R106 R801R7103J RC 10K OHM 1/10W R512 R002T4471J RC 470 OHM 1/4W
R107 R002T4101J RC 100 OHM 1/4W R513 R801R7561J RC 560 OHM 1/10W
R108 R801R7122J RC 1.2K OHM 1/10W R514 R002T2563J RC 56K OHM 1/2W
R109 R801R7222J RC 2.2K OHM 1/10W R515 R801R7103J RC 10K OHM 1/10W
R110 R801R7562J RC 5.6K OHM 1/10W R516 R002T4331J RC 330 OHM 1/4W
R111 R801R7153J RC 15K OHM 1/10W ! R517 R3X18A5R6J R,METAL OXIDE 5.6 OHM 2W
R112 R801R7473J RC 47K OHM 1/10W R518 R4X5T6222F R,METAL 2.2K OHM 1/6W
R113 R801R7562J RC 5.6K OHM 1/10W R519 R801R7101J RC 100 OHM 1/10W
R114 R801R7472J RC 4.7K OHM 1/10W R521 R002T4683J RC 68K OHM 1/4W
R115 R801R7472J RC 4.7K OHM 1/10W R522 R002T44R7J RC 4.7 OHM 1/4W
R116 R801R7103J RC 10K OHM 1/10W R523 R801R7102J RC 1K OHM 1/10W
R117 R801R7271J RC 270 OHM 1/10W R524 R801R7561J RC 560 OHM 1/10W
R120 R801R7103J RC 10K OHM 1/10W R525 R002T4102J RC 1K OHM 1/4W
R121 R002T4101J RC 100 OHM 1/4W R526 R002T4101J RC 100 OHM 1/4W
R122 R002T4750J RC 75 OHM 1/4W ! R527 R3X181R33J R,METAL OXIDE 0.33 OHM 1W
R123 R801R7103J RC 10K OHM 1/10W R528 R002T4103J RC 10K OHM 1/4W
R124 R801R7103J RC 10K OHM 1/10W R530 R801R7684J RC 680K OHM 1/10W
R125 R002T4680J RC 68 OHM 1/4W R531 R801R7102J RC 1K OHM 1/10W
R128 R801R7102J RC 1K OHM 1/10W R532 R002T4102J RC 1K OHM 1/4W
R131 R002T4472J RC 4.7K OHM 1/4W R533 R801R7471J RC 470 OHM 1/10W
R133 R002T4101J RC 100 OHM 1/4W R534 R801R7563J RC 56K OHM 1/10W
R134 R801R7103J RC 10K OHM 1/10W R535 R002T4102J RC 1K OHM 1/4W
R135 R801R7151J RC 150 OHM 1/10W R536 R002T4224J RC 220K OHM 1/4W
R138 R801R7103J RC 10K OHM 1/10W R541 R801R7273J RC 27K OHM 1/10W
R139 R801R7391J RC 390 OHM 1/10W R601 R801R7472J RC 4.7K OHM 1/10W
R140 R801R7103J RC 10K OHM 1/10W R602 R801R7101J RC 100 OHM 1/10W
R141 R801R7472J RC 4.7K OHM 1/10W R605 R002T4221J RC 220 OHM 1/4W
R142 R801R7101J RC 100 OHM 1/10W R606 R801R7101J RC 100 OHM 1/10W
R143 R801R7101J RC 100 OHM 1/10W R607 R801R7223J RC 22K OHM 1/10W
R144 R801R7103J RC 10K OHM 1/10W R608 R801R7473J RC 47K OHM 1/10W
R145 R801R7271J RC 270 OHM 1/10W R610 R801R7122J RC 1.2K OHM 1/10W
R146 R801R7103J RC 10K OHM 1/10W R611 R801R7332J RC 3.3K OHM 1/10W
R201 R801R7820J RC 82 OHM 1/10W R612 R801R7332J RC 3.3K OHM 1/10W
R202 R801R7561J RC 560 OHM 1/10W R613 R801R7332J RC 3.3K OHM 1/10W
R203 R801R7102J RC 1K OHM 1/10W R614 R801R7152J RC 1.5K OHM 1/10W
R204 R801R7391J RC 390 OHM 1/10W R615 R801R7152J RC 1.5K OHM 1/10W
R208 R801R7102J RC 1K OHM 1/10W R616 R801R7152J RC 1.5K OHM 1/10W
R213 R002T2101J RC 100 OHM 1/2W R617 R801R7102J RC 1K OHM 1/10W
R214 R801R7222J RC 2.2K OHM 1/10W R618 R801R7103J RC 10K OHM 1/10W
R215 R801R7682J RC 6.8K OHM 1/10W R619 R002T4103J RC 10K OHM 1/4W
R217 R801R7102J RC 1K OHM 1/10W R620 R002T4271J RC 270 OHM 1/4W
R218 R801R7151J RC 150 OHM 1/10W R621 R002T4561J RC 560 OHM 1/4W
R219 R801R7122J RC 1.2K OHM 1/10W R622 R801R7334J RC 330K OHM 1/10W
R221 R801R7750J RC 75 OHM 1/10W R623 R801R7102J RC 1K OHM 1/10W
R402 R002T2681J RC 680 OHM 1/2W R625 R801R7750J RC 75 OHM 1/10W
R403 R002T2681J RC 680 OHM 1/2W R628 R801R7271J RC 270 OHM 1/10W
R404 R4X5T6334F R,METAL 330K OHM 1/6W R629 R801R7271J RC 270 OHM 1/10W
R405 R4X5T6394F R,METAL 390K OHM 1/6W R630 R801R7271J RC 270 OHM 1/10W
R406 R801R7682J RC 6.8K OHM 1/10W R636 R801R7473J RC 47K OHM 1/10W
R407 R002T21R2J RC 1.2 OHM 1/2W R638 R801R7222J RC 2.2K OHM 1/10W
R408 R002T4102J RC 1K OHM 1/4W R639 R801R7562J RC 5.6K OHM 1/10W
R409 R002T2681J RC 680 OHM 1/2W R640 R801R7273J RC 27K OHM 1/10W
R410 R002T2681J RC 680 OHM 1/2W R641 R801R7223J RC 22K OHM 1/10W
! R411 R3X28A391J R,METAL OXIDE 390 OHM 2W R643 R801R7471J RC 470 OHM 1/10W
R412 R801R7822J RC 8.2K OHM 1/10W R644 R801R7272J RC 2.7K OHM 1/10W
R416 R002T22R2J RC 2.2 OHM 1/2W R645 R801R7222J RC 2.2K OHM 1/10W
R417 R4X5T6332F R,METAL 3.3K OHM 1/6W R646 R801R7822J RC 8.2K OHM 1/10W
R419 R801R7122J RC 1.2K OHM 1/10W R647 R002T2561J RC 560 OHM 1/2W
R420 R801R7103J RC 10K OHM 1/10W R702 R801R7332J RC 3.3K OHM 1/10W
R421 R002T4473J RC 47K OHM 1/4W R703 R002T4103J RC 10K OHM 1/4W
R422 R002T4821J RC 820 OHM 1/4W R706 R002T4102J RC 1K OHM 1/4W
! R424 R3X181181J R,METAL OXIDE 180 OHM 1W R707 R002T4102J RC 1K OHM 1/4W
R427 R002T4101J RC 100 OHM 1/4W R708 R801R7102J RC 1K OHM 1/10W
! R429 R655814R7J R,FUSE 4.7 OHM 1W R709 R801R7750J RC 75 OHM 1/10W
R445 R002T4184J RC 180K OHM 1/4W R710 R002T4750J RC 75 OHM 1/4W
R446 R002T2471J RC 470 OHM 1/2W R712 R002T4821J RC 820 OHM 1/4W
! R447 R635U2680J R,FUSE 68 OHM 1/2W R713 R801R7750J RC 75 OHM 1/10W
