WAVEFORMS
H-1 20AF46/20AF46C
The following waveforms were measured at the point of the corresponding
balloon number in the schematic diagram.
NOTE:
1 1V 0.1µs/div
MICON
21V 1µs/div
3 1V 50µs/div
4 1V 0.1ms/div
CHROMA
7 1V 20µs/div
8 0.5V 10ms/div
9 1V 50µs/div
10 2V 20µs/div
12 1V 2µs/div
11 0.5V 20µs/div
13 1V 20µs/div
14 2V 20µs/div
15 2V 20µs/div
16 2V 5ms/div
DEFLECTION
17 20V 5ms/div
