– 21 –
SPECIFIC INFORMATIONS
Location
No.
Part No. Description
Location
No.
Part No. Description
CAPACITORSCAPACITORS
CAPACITORSCAPACITORS
CAPACITORS
C101 24796479 ELECTROLYTICCE04G35V 4.7UF M
C102 24797101 ELECTROLYTICCE04G50V 100UF M
C104 24797100 ELECTROLYTICCE04G50V 10UF M
C105 24591102 PLASTIC FILMCQ921M 50V 1000PF J
C106 24794221 ELECTROIYTIC CE04G16V 220UF M
C108 24539474 MTPLA CAP M 50V 474J MUL
C116 24591104 PLASTIC FILMCQ921M 50V 0.1MF J
C118 24474102 CERAMIC CK141B 50V 1000PF K
C129 24474102 CERAMIC CK141B 50V 1000PF K
C161 24797478 ELECTROLYTICCE04G50V 0.47UF M
C162 24212332 CERAMIC DISKCK45 B 50V 3300PF K
C167 24763101 ELECTROLYTICCE04G16V 100UF M
C168 24794100 ELECTROLYTICCE04G16V 10UF M
C180 24797229 ELECTROLYTICCE04G50V 2.2UF M
C182 24797101 ELECTROLYTICCE04G50V 100UF M
C212 24797010 ELECTROLYTICCE04G50V 1.0UF M
C216 24797010 ELECTROLYTICCE04G50V 1.0UF M
C221 24473100 CERAMIC CC141SL 50V 10PF J
C222 24473100 CERAMIC CC141SL 50V 10PF J
C223 24473100 CERAMIC CC141SL 50V 10PF J
C224 24797100 ELECTROLYTICCE04G50V 10UF M
C225 24591104 PLASTIC FILMCQ921M 50V 0.1MF J
C226 24591104 PLASTIC FILMCQ921M 50V 0.1MF J
C233 24073077 ELECTROLYTICCE04P 50V 0.1UF M 3A
C301 24539154 MTPLA CAP M 50V 154J MUL
C302 24591152 PLASTIC FILMCQ921M 50V 1500PF J
C303 24539334 MTPLA CAP M 50V 334J MUL
C305 24617912 ELECTROLYTICCE04CH
50V 2.2UF K 3A LI
C306 24073043 ELECTROLYTICCE04P 16V
2200UF M 3A
C307 24693473 PLASTIC FILMCQ921M 100V0.047MFJ
C308 24668101 ELECTROLYTICCE04Q35V 100UF M 3A
C309 24591102 PLASTIC FILMCQ921M 50V 1000PF J
C310 24796102 ELECTROLYTICCE04G35V 1000UF M
C311 24214681 CERAMIC DISKCK45 B 500V680PF K
C313 24082057 PLASTIC FILMCF922 M 100V
220000PF J
C314 24591473 PLASTIC FILMCQ921M 50V 0.047MFJ
C317 24214471 CERAMIC DISKCK45 B 500V470PF K
C318 24212102 CERAMIC DISK CK45 B 50V 1000PF K
(21A3E/21A3M/21A3MJ)
C318 24212821 CK45B1H821K (21A3TR)
C320 24668101 ELECTROLYTICCE04Q35V 100UF M 3A
C370 24794101 ELECTROLYTICCE04G16V 100UF M
C371 24794220 ELECTROLYTICCE04G16V 22UF M
C403 24591822 PLASTIC FILM CQ921 M 50V 8200PF J
C404 24797478 ELECTROLYTICCE04G50V 0.47UF M
C408 24591183 PLASTIC FILM CQ921 M 50V 0.018MFJ
C409 24212221 CERAMIC DISK CK45 B 50V 220PF K
C410 24693472 PLASTIC FILM CQ921 M 100V4700PF J
C417 24214102 CERAMIC DISK CK45 B 500V1000PF K
C420 24666220 ELECTROLYTICCE04Q16V 22UF M 3A
C421 24666470 ELECTORLYTOC CE04Q16V
47UF M 3A
C431 24794102 ELECTROLYTICCE04G16V 1000UF M
C433 24666100 ELECTROLYTICCE04Q10V 10UF M 3A
C435 24797479 ELECTROLYTICCE04G50V 4.7UF M
C440 24082951 PLASTIC FILM CF92T 1500VH 6000PF H
C442 24082694 PLASTIC FILM CF92T 250VR33UFJ
C444 24082934 PLASTIC FILM CF92T 1500VH 1500PF H
C445 24828563 PLASTIC FILM CQ92 T 200V56000PFJ
C446 24679100 ELECTROLYTICCE04Q250V10UF M 3A
C448 24640908 ELECTROLYTICCE04H
160V33UF M 3A LI
C449 24666101 ELECTROLYTICCE04Q16V 100UF M 3A
C463 24212152 CERAMIC DISK CK45 B 50V 1500PF K
C467 24082095 PLASTIC FILM, 0.18MFD, 630V
C470 24794220 ELECTROLYTICCE04G16V 22UF M
C472 24539474 MTPLA CAP M 50V 474J MUL
C504 24591104 PLASTIC FILM CQ921 M 50V 0.1MF J
C505 24591104 PLASTIC FILM CQ921 M 50V 0.1MF J
C511 24797010 ELECTROLYTICCE04G50V 1.0UF M
C512 24212222 CERAMIC DISK CK45 B 50V 2200PF K
C517 24763101 ELECTROLYTICCE04G16V 100UF M
C521 24591104 PLASTIC FILM CQ921 M 50V 0.1MF J
C522 24591104 PLASTIC FILM CQ921 M 50V 0.1MF J
C523 24591104 PLASTIC FILM CQ921 M 50V 0.1MF J
C524 24797101 ELECTROLYTICCE04G50V 100UF M
C526 24591222 PLASTIC FILM CQ921 M 50V 2200PF J
C527 24353100 CERAMIC DISC CC45CH 50V CH 10PF C
WARNING: BEFORE SERVICING THIS CHASSIS, READ THE “X-RAY RADIATION PRECAUTION”, “SAFETY
PRECAUTION” AND “PRODUCT SAFETY NOTICE” ON PAGE 3 OF THIS MANUAL.
CAUTION: The international hazard symbols “ ” in the schematic diagram and the parts list designate com-
ponents which have special characteristics important for safety and should be replaced only with types identical to
those in the original circuit or specified in the parts list. The mounting position of replacements is to be identical with
originals. Before replacing any of these components, read carefully the PRODUCT SAFETY NOTICE. Do not
degrade the safety of the receiver through improper servicing.
NOTICE:
• The part number must be used when ordering parts, in order to assist in processing, be sure to include the Model
number and Description.
• The PC board assembly with
*
mark is no longer available after the end of the production.
Model : 21A3E, 21A3TR, 21A3M, 21A3MJ
Capacitors ............. CD : Ceramic Disk PF : Plastic Film EL : Electrolytic
Resistors ............... CF : Carbon Film CC : Carbon Composition MF : Metal Film
OMF : Oxide Metal Film VR : Variable Resistor FR : Fusible Resistor
(All CD and PF capacitors are ±5%, 50V and all resistors, ±5%, 1/6W unless otherwise noted.)
CHASSIS AND CABINET REPLACEMENT PARTS LIST
