H-2
WAVEFORMS
21PIN/AV SW
17
18
19
20
21
22
23
24
26
27
The following waveforms were measured at the point of the corresponding
balloon number in the schematic diagram.
NOTE:
20µs
1V
20µs
100mV
20µs
1V
20µs
1V
20µs
1V
20µs
1V
20µs
1V
20µs
200mV
10ms
1V
20µs
1V
16
20µs
100mV
DEFLECTION/CRT
33
34
10ms
1V
10ms
10V
31
2ms
200mV
30
2ms
200mV
