H-3
WAVEFORMS
The following waveforms were measured at the point of the corresponding
balloon number in the schematic diagram.
NOTE:
SOUND AMP
43
2ms
0.5V
40
20µs
50V
41
20µs
50V
45
0.2ms
5V
37
20µs
5V
38
39
20µs
50V
2µs
200V
35
36
10ms
10V
20µs
10V
