Connecting an aerial
Optimumreceptionofcolourrequiresagood
signalandwillgenerallymeanthatanoutdoor
aerialmustbeused.
Theexacttypeandpositioningoftheaerialwill
dependuponyourparticulararea.
YourToshibadealerorservicepersonnelcan
bestadviseyouonwhichaerialtouseinyour
area.
Beforeconnectingtheaerialcable,turnoffall
mainpowerswitches.
IN
OUT
VHF and/or
UHF aerial
300 7 twin-lead feeder
75 7
aerial
terminal
Aerial adaptor
(not supplied)
Aerial cable (75 7 coaxial)
(not supplied)
75 7 aerial
terminal
75 7 coaxial cable
Plug
(not supplied)
Media Recorder
TV back view
Exploring your new TV
Installing the remote control batteries
Removethebatterycover.
InserttwoR03(AAA)batteriesmatchingthe–/+
polaritiesofthebatterytothe–/+marksinside
thebatterycompartment.
Introduction / Getting started
Cautions:
• Dispose of batteries in a designated disposal
area. Batteries must not be exposed to
excessive heat such as sunshine, fire or the
like.
• Attentionshouldbedrawntotheenvironmental
aspects of battery disposal.
• Nevermixbatterytypesorcombineused
batterieswithnewones.
Notes:
• If the remote control does not operate correctly,
or if the operating range becomes reduced,
replacebothbatterieswithnewones.
• Ifthebatteriesaredeadorifyouwillnotuse
the remote control for a long time, remove the
batteries to prevent battery acid from leaking
into the battery compartment.
Effective range
within 5 m
TV front and side panel controls
• YoucanoperateyourTVusingthebuttonson
thesidepanelortheremotecontrol.Theback
ofthepanelprovidetheterminalconnections
toconnectotherequipmenttoyourTV(-
“ConnectingyourTV”pages23–28).
• Fortheuseofeachcontrol,seethepagesin
brackets.
