English - 44 -
English
Appendix C: Supported File Formats for USB Mode
Media
File
Extension
Format
Remarks
(Maximum resolution/Bit rate etc.)
Video Audio
Movie
.mpg, .mpeg MPEG1, 2 MPEG Layer 1/2/3
max 1920x1080 @ 30
p 20Mbit/sec
.dat MPEG1, 2
MPEG2
.vob MPEG2
.mkv H.264, MPEG1,2,4 EAC3 / AC3
.mp4 MPEG4, H.264 PCM/MP3
.avi
MPEG2, MPEG4 PCM/MP3
max 1920x1080 @ 30p 20Mbit/sec
H.264 PCM
Music .mp3 -
MPEG 1 Layer 1 / 2
(MP3)
32kbps ~ 320kbps(Bit rate)
32kHz ~ 48kHz(Sampling rate)
.jpg .jpeg
Baseline JPEG max WxH = 15360x8640 4147200bytes
Progressive JPEG max WxH = 1024x768 6291456bytes
.bmp - max WxH = 9600x6400 3840000bytes
Subtitle
.sub
--
.srt
Appendix D: PIN Information
Before connecting any external equipment, turn off all main power switches. If there is no switch, remove the
mains plug from the wall socket.
Signal information for Mini D-sub 15 pin connector
Pin No. Signal name Pin No. Signal name Pin No. Signal name
1 R 6 Ground 11 NC
2 G 7 Ground 12 NC
3 B 8 Ground 13 H-sync
4 NC* 9 NC 14 V-sync
5 NC 10 Ground 15 NC
* NC = not connected
