Toshiba 32HF72 User Manual

Introduction
Connecting
your TV
Using the
Remote Control
Setting up
your TV
Using the TV’s
Features
Appendix
Index
50
(E) 32HF72 36HF72
Television System NTSC standard
Channel Coverage VHF: 2 through 13
UHF: 14 through 69
Cable TV: Mid band (A-8 through A-1, A through I)
Super band (J through W)
Hyper band (AA through ZZ, AAA, BBB)
Ultra band (65 through 94, 100 through 125)
Power Source 120 V AC, 60 Hz
Power Consumption 32HF72: 186 W (average)
36HF72: 180 W (average)
Audio Power 10 W + 10 W
Speaker Type Two 2-3/8 × 4-3/4 inches (60 × 120 mm)
Video/Audio Terminals S-VIDEO INPUT
Y: 1 V(p-p), 75 ohm, negative sync.
C: 0.286 V(p-p) (burst signal), 75 ohm
VIDEO/AUDIO INPUT
VIDEO: 1 V(p-p), 75 ohm, negative sync.
AUDIO: 150 mV(rms) (30% modulation equivalent, 47 k ohm)
ColorStream
®
(component video) INPUT
Y: 1V(p-p), 75 ohm
PB: 0.7 V(p-p), 75 ohm
P
R: 0.7 V(p-p), 75 ohm
AUDIO: 150 mV(rms), 47 k ohm
VIDEO/AUDIO OUTPUT
VIDEO: 1 V(p-p), 75 ohm, negative sync.
AUDIO: 150 mV(rms) (30% modulation equivalent, 4.7 k ohm)
VARIABLE AUDIO OUTPUT
0–300 mV(rms) (30% modulation equivalent, 4.7 k ohm)
AUDIO CENTER CHANNEL INPUT
300 mV(rms) (30% modulation equivalent, 10 k ohm)
Dimensions 32HF72: Width 34-1/2 inches (875 mm)
Height 26-1/2 inches (673 mm)
Depth 22-5/8 inches (575 mm)
36HF72: Width 38-3/16 inches (970 mm)
Height 29-9/16 inches (751 mm)
Depth 24-1/4 inches (615 mm)
Mass 32HF72: 151 lbs. (68.5 kg)
36HF72: 203 lbs. (92.1 kg)
Supplied Accessories Remote Control with 2 size “AA” alkaline batteries
Optional TV stand 32HF72: ST3262
36HF72: ST3662
Design and specifications are subject to change without notice.
Appendix
Specifications
