L/C 100_U
19
2000 L/C 100 (OM60866U)
2. Remove the module from the key
frame.
3. Remove the 2 screws to take out the
lid of the module. Take out the dis-
charged battery and put a new battery
with the positive side up.
NOTICE
Do not bend the terminals.
4. Install the lid with the 2 screws.
5. Install the module into the key frame
and secure the cover with the screw.
6. When pushing any switch on the wire-
less key, make sure the indicator light
comes on.
NOTICE
Make sure the positive side and
negative side of the battery should
be faced correctly.
Be careful not to bend the electrode
of the battery insertion and that
dust or oils do not adhere to the
case.
Take care not to lose the screws.
Close the cover securely.
To Next Page
