’01 L/C U (L/O 0008)
19
2. Remove the module from the key
frame.
3. Remove the 2 screws to take out the
lid of the module. Take out the dis-
charged battery and put a new battery
with the positive side up.
NOTICE
Do not bend the terminals.
4. Install the lid with the 2 screws.
5. Install the module into the key frame
and secure the cover with the screw.
6. When pushing any switch on the wire-
less key, make sure the indicator light
comes on.
NOTICE
! Make sure the positive side and
negative side of the battery should
be faced correctly.
! Be careful not to bend the electrode
of the battery insertion and that
dust or oils do not adhere to the
case.
! Take care not to lose the screws.
! Close the cover securely.
To Next Page
