Toyota 86120-02360 User Manual

Ref.
No.
Part No. Part Name & Description Remarks
R755 ERJ6GEYJ104 Chip, 100kΩ
ΩΩ
Ω 1/10W
R762 ERJ8GEYJ561V Chip, 560Ω
ΩΩ
Ω 1/8W
R764 ERJ8GEYJ102V Chip, 1kΩ
ΩΩ
Ω 1/8W
R768 ERJ6RBD473V Metal Film, 47kΩ
ΩΩ
Ω 1/10W
R769 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω 1/10W
R770 ERJ6GEYJ123 Chip, 12kΩ
ΩΩ
Ω 1/10W
R783 ERJ8GEYJ102V Chip, 1kΩ
ΩΩ
Ω 1/8W
CONNECTORs
CN631 YEAE9604S17S Connector, 17P
CN632 YEAE0110TKAG Connector, 10P
CN701 YEAE012462 Connector, 10P+6P
CN702 YEAE012463 Connector, 12P
CN901 YEAE0105MX Connector, 5P
CN902 YEAE0105MX Connector, 5P
CN903 YEAE0105MX Connector, 5P
COILs
L50 G1C3R3J00003 Coil
L105 G1C1R0J00003 Coil
L451 YELT03N101JT Coil
L601 YELTBLM21A10 Coil
L602 YELTBLM21A10 Coil
L603 YELTBLM21A10 Coil
L604 YELT03N101JT Coil
L701 G0A151J00005 Coil
CRYSTALs
XL451 H0D720400003 Crystal
XL601 YEXL49U0629T Crystal
NEON TUBE
Z51 J0LE00000004 Neon Tube
NETWORK RESISTORs
R661 EXBV8V102JV 1kΩ
ΩΩ
Ω
R663 EXBV8V102JV 1kΩ
ΩΩ
Ω
R664 EXBV8V102JV 1kΩ
ΩΩ
Ω
R665 EXBV8V102JV 1kΩ
ΩΩ
Ω
R667 EXBV8V102JV 1kΩ
ΩΩ
Ω
R668 EXBV8V102JV 1kΩ
ΩΩ
Ω
R669 EXBV8V102JV 1kΩ
ΩΩ
Ω
R670 EXBV8V102JV 1kΩ
ΩΩ
Ω
[E8094] Fix-EQ. Block
IC´s and TRANSISTORs
IC1 YEAMPC4570T1 IC
IC2 YEAMTA2062FL IC
IC3 YEAMPC4570T1 IC
IC61 YEAMPC4570T1 IC
IC62 YEAMTA2062FL IC
CAPACITORs
C1 YECUS1C104KX Ceramic, 0.1µF 16WV
C2 YECUS1C104KX Ceramic, 0.1µF 16WV
C3 YECUS1H681JM Ceramic, 680PF 50WV
C4 YECUS1H822KX Ceramic, 8200PF 50WV
C8 YECUS1E223KX Ceramic, 0.022µF 25WV
C9 YECUS1H822KX Ceramic, 8200PF 50WV
C11 YECUS1C474KX Ceramic, 0.47µF 16WV
C12 YECUS1C823KX Ceramic, 0.082µF 16WV
C13 YECUS1H472KX Ceramic, 4700PF 50WV
C14 YECUS1H561KX Ceramic, 560PF 50WV
C21 YECUS1C104KX Ceramic, 0.1µF 16WV
C22 YECUS1C104KX Ceramic, 0.1µF 16WV
Ref.
No.
Part No. Part Name & Description Remarks
C23 YECUS1E223KX Ceramic, 0.022µF 25WV
C24 YECUS1C474KX Ceramic, 0.47µF 16WV
C26 YECUS1C224KX Ceramic, 0.22µF 16WV
C27 YECUS1E223KX Ceramic, 0.022µF 25WV
C29 YECUS1H392KX Ceramic, 3900PF 50WV
C30 YECUS1E333KX Ceramic, 0.033µF 25WV
C31 YECUS1H561KX Ceramic, 560PF 50WV
C61 YECUS1C104KX Ceramic, 0.1µF 16WV
C62 YECUS1C104KX Ceramic, 0.1µF 16WV
C63 YECUS1H681JM Ceramic, 680PF 50WV
C64 YECUS1H822KX Ceramic, 8200PF 50WV
C68 YECUS1E223KX Ceramic, 0.022µF 25WV
C69 YECUS1H822KX Ceramic, 8200PF 50WV
C71 YECUS1C474KX Ceramic, 0.47µF 16WV
C72 YECUS1C823KX Ceramic, 0.082µF 16WV
C73 YECUS1H472KX Ceramic, 4700PF 50WV
C74 YECUS1H561KX Ceramic, 560PF 50WV
C81 YECUS1C104KX Ceramic, 0.1µF 16WV
C82 YECUS1C104KX Ceramic, 0.1µF 16WV
C83 YECUS1E223KX Ceramic, 0.022µF 25WV
C84 YECUS1C474KX Ceramic, 0.47µF 16WV
C86 YECUS1C224KX Ceramic, 0.22µF 16WV
C87 YECUS1E223KX Ceramic, 0.022µF 25WV
C89 YECUS1H392KX Ceramic, 3900PF 50WV
C90 YECUS1E333KX Ceramic, 0.033µF 25WV
C91 YECUS1H561KX Ceramic, 560PF 50WV
RESISTORs
R1 ERJ6GEYJ332 Chip, 3.3kΩ
ΩΩ
Ω 1/10W
R2 ERJ6GEYJ223 Chip, 22kΩ
ΩΩ
Ω 1/10W
R3 ERJ6GEYJ104 Chip, 100kΩ
ΩΩ
Ω 1/10W
R4 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω 1/10W
R5 ERJ6GEYJ332 Chip, 3.3kΩ
ΩΩ
Ω 1/10W
R6 ERJ6GEYJ222 Chip, 2.2kΩ
ΩΩ
Ω 1/10W
R8 ERJ6GEYJ561 Chip, 560Ω
ΩΩ
Ω 1/10W
R9 ERJ6GEYJ272 Chip, 2.7kΩ
ΩΩ
Ω 1/10W
R10 ERJ6GEYJ473 Chip, 47kΩ
ΩΩ
Ω 1/10W
R21 ERJ6GEYJ332 Chip, 3.3kΩ
ΩΩ
Ω 1/10W
R22 ERJ6GEYJ223 Chip, 22kΩ
ΩΩ
Ω 1/10W
R23 ERJ6GEYJ563 Chip, 56kΩ
ΩΩ
Ω 1/10W
R24 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω 1/10W
R25 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω 1/10W
R26 ERJ6GEYJ332 Chip, 3.3kΩ
ΩΩ
Ω 1/10W
R28 ERJ6GEYJ272 Chip, 2.7kΩ
ΩΩ
Ω 1/10W
R61 ERJ6GEYJ332 Chip, 3.3kΩ
ΩΩ
Ω 1/10W
R62 ERJ6GEYJ223 Chip, 22kΩ
ΩΩ
Ω 1/10W
R63 ERJ6GEYJ104 Chip, 100kΩ
ΩΩ
Ω 1/10W
R64 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω 1/10W
R65 ERJ6GEYJ332 Chip, 3.3kΩ
ΩΩ
Ω 1/10W
R66 ERJ6GEYJ222 Chip, 2.2kΩ
ΩΩ
Ω 1/10W
R68 ERJ6GEYJ561 Chip, 560Ω
ΩΩ
Ω 1/10W
R69 ERJ6GEYJ272 Chip, 2.7kΩ
ΩΩ
Ω 1/10W
R70 ERJ6GEYJ473 Chip, 47kΩ
ΩΩ
Ω 1/10W
R81 ERJ6GEYJ332 Chip, 3.3kΩ
ΩΩ
Ω 1/10W
R82 ERJ6GEYJ223 Chip, 22kΩ
ΩΩ
Ω 1/10W
R83 ERJ6GEYJ563 Chip, 56kΩ
ΩΩ
Ω 1/10W
R84 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω 1/10W
R85 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω 1/10W
R86 ERJ6GEYJ332 Chip, 3.3kΩ
ΩΩ
Ω 1/10W
R88 ERJ6GEYJ272 Chip, 2.7kΩ
ΩΩ
Ω 1/10W
CONNECTORs
CN1 YEAE0107ISK Connector, 7P
CN2 YEAE0108ISK Connector, 8P
[E9064] Display Block
IC´s and TRANSISTORs
IC901 YEAMLC75853 IC
12
CQ-LS7230K

Toyota 86120-02360 Specifications

General

Brand	Toyota
Model	86120-02360
Category	Car Receiver
Language	English
