12 TAPE PLAYER PARTS
Ref.
No.
Part No. Part Name & Description Remarks
[8790A] Tape Dolby Block
ICs AND TRANSISTORs
IC1 C1BB00000100 IC
Q401 YEANC114YKT Transistor
CAPACITORs
C201 YECUS1H331JM Ceramic, 330PF 50WV
C202 YECUS1H331JM Ceramic, 330PF 50WV
C204 YECUS1H123KX Ceramic, 0.012µF 50WV
C205 YECUS1E333KX Ceramic, 0.033µF 25WV
C206 YECUS1C104KX Ceramic, 0.1µF 16WV
C301 YECUS1H331JM Ceramic, 330PF 50WV
C302 YECUS1H331JM Ceramic, 330PF 50WV
C304 YECUS1H123KX Ceramic, 0.012µF 50WV
C305 YECUS1E333KX Ceramic, 0.033µF 25WV
C306 YECUS1C104KX Ceramic, 0.1µF 16WV
C401 ECA1CSA220I Electrolytic, 22µF 16WV
C402 ECEA1AKS330I Electrolytic, 33µF 10WV
C403 YECUV2A103KX Ceramic, 0.01µF 100WV
C404 YECUS1E333KX Ceramic, 0.033µF 25WV
C405 ECA1HSAR33I Electrolytic, 0.33µF 50WV
C406 YECUS1H472KX Ceramic, 0.0047µF 50WV
C407 ECEA1CKS100I Electrolytic, 10µF 16WV
C409 YECUS1H472KX Ceramic, 0.0047µF 50WV
C501 YECUV1E334ZF Ceramic, 0.33µF 25WV
RESISTORs
R201 ERJ6GEYJ683 Chip, 68kΩ
ΩΩ
Ω 1/10W
R202 ERJ6GEYJ683 Chip, 68kΩ
ΩΩ
Ω 1/10W
R207 ERJ8GEYJ181V Chip, 180Ω
ΩΩ
Ω 1/8W
R301 ERJ6GEYJ683 Chip, 68kΩ
ΩΩ
Ω 1/10W
R302 ERJ6GEYJ683 Chip, 68kΩ
ΩΩ
Ω 1/10W
R307 ERJ6GEYJ181 Chip, 180Ω
ΩΩ
Ω 1/10W
R402 ERJ6GEYJ183 Chip, 18kΩ
ΩΩ
Ω 1/10W
R403 ERJ6GEYJ473 Chip, 47kΩ
ΩΩ
Ω 1/10W
R404 ERJ8GEYJ334V Chip, 330kΩ
ΩΩ
Ω 1/8W
R405 ERJ8GEYJ392V Chip, 3.9kΩ
ΩΩ
Ω 1/8W
R406 ERJ6GEYJ273 Chip, 27kΩ
ΩΩ
Ω 1/10W
R408 ERJ8GEYJ223V Chip, 22kΩ
ΩΩ
Ω 1/8W
R409 ERJ6GEYJ273 Chip, 27kΩ
ΩΩ
Ω 1/10W
R501 ERJ6GEYJ472 Chip, 4.7kΩ
ΩΩ
Ω 1/10W
CONNECTORs
CN1 YEAE012385 Connector, 17P
CN3 YEAESLW05R1 Connector, 5P
SWITCHes
SW1 K0J1CB00001 Switch
SW2 YEAS07174 Switch
SW3 YEAS08042 Switch
VARIABLE RESISTORs
VR201 EVNDXAA00B13 Variable Resistor
VR301 EVNDXAA00B13 Variable Resistor
[E8791] Tape Reel Block
PHOTOCOUPLERs
TE1 YEADRPI221 Photocoupler
TE2 YEADRPI221 Photocoupler
CAPACITORs
C1 YECUS1H471JM Ceramic, 470PF 50WV
C2 YECUS1H471JM Ceramic, 470PF 50WV
C3 YECUS1H471JM Ceramic, 470PF 50WV
RESISTORs
R1 ERJ8GEYJ683V Chip, 68kΩ
ΩΩ
Ω 1/8W
R2 ERJ8GEYJ683V Chip, 68kΩ
ΩΩ
Ω 1/8W
R3 ERJ6GEYJ472 Chip, 4.7kΩ
ΩΩ
Ω 1/10W
Ref.
No.
Part No. Part Name & Description Remarks
R4 ERJ8GEYJ472V Chip, 4.7kΩ
ΩΩ
Ω 1/8W
R5 ERJ8GEYJ472V Chip, 4.7kΩ
ΩΩ
Ω 1/8W
R6 ERJ8GEYJ472V Chip, 4.7kΩ
ΩΩ
Ω 1/8W
R7 ERJ8GEYJ821V Chip, 820Ω
ΩΩ
Ω 1/8W
R8 ERJ8GEYJ821V Chip, 820Ω
ΩΩ
Ω 1/8W
CONNECTORs
CN2 YEAE0110TKCR Connector, 10P
JP3 YGAJ071387A CORD W/Connector
SWITCHes
SW4 YEAS07174 Switch
SW5 EVQWJE001 Rotary Switch
Mechanical Parts
MISCELLANEOUS
1 YGFX0052472 Lock Plate Spring
2 YGFX0052454 Spring
3 YGFX0462100 Cassette Holder (U) Ass´y
4 YGFX0462104 Cassette Holder(L)
5 YGFA011830 Head Chassis Ass´y
6 YGFX234194 Cam
7 YGFX0052427 Back Tension Spring
8 YGFX209271 Reel (R) Ass´y
9 YGFX0052471 Holding Spring
10 YGJW04131 Washer
11 YGFX0052475 Rack Plate Spring
12 YGFX0031035 Rack Plate
13 YGFA011827 Main Chassis Ass´y
14 YGFX0052444 EQ Lever Spring
15 YGFW062546 Shaft
16 YGP0PT8790A1 Dolby P.C.B. Ass´y
17 YGP9FZ2973 Head Ass´y
18 YGFX0462105 Lever
19 YGFX0052478 Vibration-proof Spring
20 YGFX0052477 Spring
21 YGFX239470 Cassette Guid Plate
22 YGFX0462097 PRO Change Plate
23 YGFX0031031 Idler Gear Plate (F) Ass´y
24 YGP0FX3845 Main Motor Ass´y
25 YGFX0052474 Rack Return Spring
26 YGFX218305 Pinch Roller (F) Ass´y
28 YGFX0031033 Idler Gear Plate (R) Ass´y
29 YGFX0462102 Rack Return Link
30 YGFW062600 Rack Return Link Shaft
31 YGFX218306 Pinch Roller (R) Ass´y
32 YGFX213213 Flywheel Ass´y
33 YGFX0031001 Drive Gear (2)
34 YEFX003753B Play Idler Gear
35 YGFX014075 Lock Ling
36 YGFX003970 Gear
37 YGJT03250 Gear Shaft
38 YGFX0052446 Idler Gear Plate Spring
39 YGFX0031030 Worm Gear
40 YGP0FX3846 Loading Motor Ass´y
41 YGFX030102 Worm Gear Stopper
42 YGFX0031026 Drive Gear (3)
43 YGFA011851 Drive Chassis Ass´y
44 YGP0PT8791A0 Reel P.C.B. Ass´y
46 YGFX209270 Reel (F) Ass´y
47 YGFX0052473 Pinch Roller Spring
50 YGFX003971 PRO Change Gear
52 YEFR03083 Belt
54 YGFX0031029 Drive Gear
61 YEJE01004 E-Ring
62 YEJE01036 E-Ring
64 XYN2+C8FX Screw, 2 x 8mm
65 YEJT03167 Screw
66 YEJS06097A Screw, 2 x 2.5mm
67 YEJT03271 Screw
15
CQ-LS7230K
