For details, refer to “Service reminder indicators and warning buzzers,” Section 1-6, 2007
Owner’s Manual.
OVERVIEW
When the anti-lock brake system (ABS) function is in action, you may feel the
brake pedal pulsating and hear a noise. In this situation, to let the anti-lock
brake system work for you, just hold the brake pedal down more firmly. Do not
pump the brake as this will result in reduced braking performance.
Indicator symbols
Indicator cluster
4
OVERVIEW
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
Anti-lock Brake System warning light
1
Automatic headlight leveling system warning
Engine oil replacement reminder
1
Smart Key system warning
1
Headlight indicator
Headlight high beam indicator
Turn signal indicator
Cruise control indicator
2
or Dynamic Laser Cruise Control indicator
3
Dynamic Laser Cruise Control ready mode indicator
Conventional cruise control mode indicator
Slip indicator
Automatic T
ransmission indicator
Airbag SRS warning
1
Vehicle Stability Control/Traction Control warning
Low windshield washer fluid level warning
Engine immobilizer/Theft deterrent system indicator
Engine coolant temperature
Service indicator and reminder
Tachometer
Speedometer
Fuel gauge
Low fuel level warning light
Trip meter reset
Odometer and two trip meters
Sequential shift display
Dynamic Laser Cruise Control display
Dynamic Laser Cruise Control master warning light
Brake system warning
1
Battery warning
1
Malfunction/Check Engine indicator
1
“AIRBAG ON” indicator
Low engine oil pressure warning
1
“AIRBAG OFF” indicator
2
If this light flashes, refer to “Cruise control,” Section 1-7, 2007 Owner’s Manual.
3
If this light flashes, refer to “Dynamic laser cruise control,” Section 1-7, 2007 Owner’s
Manual.
Open door warning
1
5
Driver seat belt reminder
1
(alarm will sound if speed is over 9 mph)
Front passenger seat belt reminder
1
(alarm will sound if speed is over 9 mph)
Low Tire Pressure Warning
1
07 Avalon iGuide Inside 9/25/06 1:53 PM Page 4
