Page #113 background imageLoading...
Page #113 background image
109
FAQ
Q1. What should I do if I forget my wireless password?
The default wireless password is printed on the label of the router. If the password has
been altered:
1. Connect your computer to the router using an Ethernet cable.
2. Visit http://tplinkwifi.net, and log in with your TP-Link ID or the password you set for
the router.
3. Go to Wireless or Advanced > Wireless to retrieve or reset your wireless password.
Q2. What should I do if I forget my web management password?
If you are using a TP-Link ID to log in, or you have enabled the Password Recovery
feature of the router, click Forgot Password? on the login page and then follow the
instructions to reset it.
Alternatively, press and hold the Reset button of the router until the LED binks to reset
it, and then visit http://tplinkwifi.net to create a new login password.
Note:
Please refer to Password Recovery to learn how to configure Password Recovery.
You’ll need to reconfigure the router to surf the internet once the router is reset, and please mark down your new
password for future use.
Q3. What should I do if I cannot log in to the router’s web management
page?
This can happen for a variety of reasons. Please try the methods below to log in again.
Make sure your computer is connected to the router correctly and the corresponding
LED indicator(s) light up.
Make sure the IP address of your computer is configured as Obtain an IP address
automatically and Obtain DNS server address automatically.
Make sure http://tplinkwifi.net or http://192.168.0.1 is correctly entered.
Check your computer’s settings:
1 ) Go to Start > Control Panel > Network and Internet, and click View network
status and tasks.
2 ) Click Internet Options on the bottom left.
3 ) Click Connections and select Never dial a connection.

Table of Contents

Other manuals for TP-Link Archer AX11000

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the TP-Link Archer AX11000 and is the answer not in the manual?

TP-Link Archer AX11000 Specifications

General IconGeneral
Flash memory512 MB
CertificationFCC, CE, RoHS
Internal memory1024 MB
Processor cores4
Built-in processorYes
Processor frequency1800 MHz
DSL WANNo
WAN connection typeRJ-45
Wi-Fi bandTri-band (2.4 GHz / 5 GHz / 5 GHz)
Wi-Fi standards802.11a, 802.11ad, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Top Wi-Fi standardWi-Fi 6 (802.11ax)
WLAN data transfer rate (max)4804 Mbit/s
WLAN data transfer rate (third band)1148 Mbit/s
Product typeTabletop router
Product colorBlack
VPN supportPPTP, OpenVPN
Cabling technology10/100/1000Base-T(X)
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Receiver sensitivity5 GHz_1: 11a 6Mbps:-96dBm, 11a 54Mbps:-78dBm 11ac VHT20_MCS0:-95dBm, 11ac VHT20_MCS11:-65dBm 11ac VHT40_MCS0:-93dBm, 11ac VHT40_MCS11:-62dBm 11ac VHT80_MCS0:-90dBm, 11ac VHT80_MCS11:-59dBm 11ac VHT160_MCS0:-87dBm, 11ac VHT160_MCS11:-54dBm 11ax HE20_MCS0:-94dBm, 11ax HE20_MCS11:-62Bm 11ax HE40_MCS0:-91dBm, 11ax HE40_MCS11:-59dBm 11ax HE80_MCS0:-88dBm, 11ax HE80_MCS11:-57dBm 11ax HE160_MCS0:-84dBm, 11ax HE160_MCS11:-54dBm 5 GHz_2: 11a 6Mbps:-96dBm, 11a 54Mbps:-78dBm 11ac VHT20_MCS0:-95dBm, 11ac VHT20_MCS11:-65dBm 11ac VHT40_MCS0:-93dBm, 11ac VHT40_MCS11:-62dBm 11ac VHT80_MCS0:-90dBm, 11ac VHT80_MCS11:-59dBm 11ac VHT160_MCS0:-87dBm, 11ac VHT160_MCS11:-54dBm 11ax HE20_MCS0:-94dBm, 11ax HE20_MCS11:-62Bm 11ax HE40_MCS0:-91dBm, 11ax HE40_MCS11:-59dBm 11ax HE80_MCS0:-88dBm, 11ax HE80_MCS11:-57dBm 11ax HE160_MCS0:-84dBm, 11ax HE160_MCS11:-54dBm 2.4 GHz: 11g 6Mbps:-97dBm, 11a 54Mbps:-79dBm 11n HT20_MCS0:-97dBm, 11n HT20_MCS7:-78dBm 11n HT40_MCS0:-95dBm, 11n HT40_MCS7:-75dBm 11ac VHT20_MCS0:-96dBm, 11ac VHT20_MCS11:-67dBm 11ac VHT40_MCS0:-94dBm, 11ac VHT40_MCS11:-64dBm 11ax HE20_MCS0:-96dBm, 11ax HE20_MCS11:-64dBm 11ax HE40_MCS0:-93dBm, 11ax HE40_MCS11:-61dBm
Ethernet LAN data rates10, 100, 1000 Mbit/s
Ethernet LAN interface typeGigabit Ethernet
Number of guest networks (2.4 GHz)1
Transmit powerCE: \u003C20dBm(2.4GHz), \u003C23dBm(5.15GHz~5.35GHz); \u003C30dBm(5.47GHz~5.725GHz); FCC: \u003C30dBm(2.4GHz & 5.15GHz~5.25GHz & 5.725GHz~5.825GHz), \u003C24dBm(5.25GHz-5.35GHz & 5.47GHz-5.725 GHz) dBmW
Antennas quantity8
Security algorithms64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Supported network protocolsIPv4, IPv6
Package depth290 mm
Package width365 mm
Package height120 mm
Package weight2590 g
Number of products included1 pc(s)
Cables includedLAN (RJ-45)
Browser supportedInternet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0
Windows operating systems supportedWindows 10, Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows NT, Windows Vista, Windows XP
Storage temperature (T-T)-40 - 70 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)5 - 90 %
Operating relative humidity (H-H)10 - 90 %
Output current5 A
Output voltage12 V
Power source typeDC
Weight and Dimensions IconWeight and Dimensions
Width288 mm
Height184 mm
