101
FAQ
Q1. What should I do if I forget my wireless password?
The default wireless password is printed on the label of the router. If the password has
been altered:
1. Connect your computer to the router using an Ethernet cable.
2. Visit http://tplinkwifi.net, and log in with your TP-Link ID or the password you set for
the router.
3. Go to Basic > Wireless to retrieve or reset your wireless password.
Q2. What should I do if I forget my web management password?
If you are using a TP-Link ID to log in, or you have enabled the Password Recovery
feature of the router, click Forgot password on the login page and then follow the
instructions to reset it.
Alternatively, press and hold the Reset button of the router until the LED turns
circulating blue to reset it, and then visit http://tplinkwifi.net to create a new login
password.
Note:
Please refer to Password Recovery to learn how to configure Password Recovery.
You’ll need to reconfigure the router to surf the internet once the router is reset, and please mark down your new
password for future use.
Q3. What should I do if I can’t log in to the router’s web management
page?
This can happen for a variety of reasons. Please try the methods below to log in again.
Make sure your computer is connected to the router correctly and the corresponding
LED indicator(s) light up.
Make sure the IP address of your computer is configured as Obtain an IP address
automatically and Obtain DNS server address automatically.
Make sure http://tplinkwifi.net or http://192.168.0.1 is correctly entered.
Check your computer’s settings:
1 ) Go to Start > Control Panel > Network and Internet, and click View network
status and tasks.
2 ) Click Internet Options on the bottom left.
3 ) Click Connections and select Never dial a connection.

Table of Contents

Other manuals for TP-Link Archer AX6000

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the TP-Link Archer AX6000 and is the answer not in the manual?

TP-Link Archer AX6000 Specifications

General IconGeneral
DSL WANNo
Ethernet WANYes
WAN connection typeRJ-45
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Wi-Fi standards802.11a, Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standardWi-Fi 6 (802.11ax)
WLAN data transfer rate (max)4804 Mbit/s
Number of WLAN connections (max)8
WLAN data transfer rate (first band)1148 Mbit/s
Product typeTabletop router
Product colorBlack
LED indicatorsLAN, Power, Status, USB, WAN, WLAN
Flash memory128 MB
CertificationFCC, CE, RoHS
Internal memory1 MB
Processor cores4
Processor frequency1860 MHz
Memory card slot(s)-
USB 2.0 ports quantity0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity1
Cabling technology10/100/1000Base-T(X)
Networking standardsIEEE 802.11ax, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Receiver sensitivity5GHz: 11a 6Mbps: -97dBm, 11a 54Mbps:-79dBm 11ac VHT20_MCS0:-96dBm, 11ac VHT20_MCS11:-66dBm 11ac VHT40_MCS0:-94dBm, 11ac VHT40_MCS11:-63dBm 11ac VHT80_MCS0:-91dBm, 11ac VHT80_MCS11:-60dBm 11ac VHT160_MCS0:-88dBm, 11ac VHT160_MCS11:-55dBm 11ax HE20_MCS0:-95dBm, 11ax HE20_MCS11:-63dBm 11ax HE40_MCS0:-92dBm, 11ax HE40_MCS11:-60dBm 11ax HE80_MCS0:-89dBm, 11ax HE80_MCS11:-58dBm 11ax HE160_MCS0:-85dBm, 11ax HE160_MCS11:-55dBm 2.4GHz: 11g 6Mbps: -97dBm, 11a 54Mbps:-79dBm 11n HT20_MCS0:-97dBm, 11n HT20_MCS7:-78dBm 11n HT40_MCS0:-95dBm, 11n HT40_MCS7:-75dBm 11ac VHT20_MCS0:-96dBm, 11ac VHT20_MCS11:-67dBm 11ac VHT40_MCS0:-94dBm, 11ac VHT40_MCS11:-64dBm 11ax HE20_MCS0:-96dBm, 11ax HE20_MCS11:-64dBm 11ax HE40_MCS0:-93dBm, 11ax HE40_MCS11:-61dBm
Ethernet LAN data rates10, 1000 Mbit/s
Ethernet LAN interface typeGigabit Ethernet
Output current4 A
Output voltage12 V
Power source typeDC
Storage temperature (T-T)-40 - 70 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)5 - 90 %
Operating relative humidity (H-H)10 - 90 %
Transmit powerCE: \u003C20dBm(2.4GHz), \u003C23dBm(5.15GHz~5.35GHz); \u003C30dBm(5.47GHz~5.725GHz), FCC: \u003C30dBm(2.4GHz & 5.15GHz~5.25GHz & 5.725GHz~5.825GHz) dBmW
Package depth290 mm
Package width365 mm
Package height120 mm
Package weight1820 g
Number of products included1 pc(s)
Cables includedLAN (RJ-45)
Firewall securityDoS, SPI Firewall, IP and MAC Address Binding
Security algorithms64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Mac operating systems supportedmacOS
Windows operating systems supportedWindows 10, Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows XP
Weight and Dimensions IconWeight and Dimensions
Width261.3 mm
Height60.5 mm
