TP-Link RE365 User Manual

Q1. What should I do if the Tether app cannot nd my device?
1. Connect your smartphone to the extender’s network
TP-Link_Extender_2.4GHz or TP-Link_Extender_5GHz.
2. Launch the Tether app, and select your extender.
Tip: If you have connected to the extender’s Wi-Fi but still cannot find your device, turn off
your cellular data.
3. Follow app instructions to complete the setup.
If you are still having problems, contact our technical support.
Q2. What should I do if the LED doesn’t turn solid on after
completing setup via the Tether app or web browser?
You may have entered incorrect Wi-Fi passwords for your host router during the
conguration. Check the passwords and try again.
Make sure the extender is close to your router, preferably within 16 feet, and
away from large electrical appliances.
If you have enabled wireless MAC ltering, wireless access control, or access
control list (ACL) on your router, disable them rst, then follow any method on the
front page to complete the conguration.
Try setting it up via the WPS button.
Reset the extender and go through the conguration again.
If you are still having problems, contact our technical support.
LED Status Indication (For Range Extender Mode)
5GHz On/O
2.4GHz
Ethernet
On/O
On/O
The extender is connected or not connected to the
5GHz wireless network of your router.
The extender is connected or not connected to the
2.4GHz wireless network of your router.
The extender is on or o.
The system is starting up or rmware upgrade is in
progress.
Power
On/O
Blinking
(Signal)
The extender is connected to your router’s wireless
network and is in a suitable location.
The extender is receiving a weak signal. Try relocating
it closer to your router.
WPS connection is in progress.
No wireless connection is established.
Solid blue
Solid red
Blinking
O
LED Explanation
Q3. How do I reset the extender?
With the extender powered on, use a pin to press the Reset button until all LEDs
turn on momentarily, then release the button. The extender will reboot.
Reset
Wi-Fi
Wi-Fi
TP-Link_Extender_2.4GHz
CHOOSE A NETWORK...
Other...
< Settings
TP-Link_Extender_5GHz
My Devices
Local Device
RE365
XX-XX-XX-X X-XX-X X
Safety Information
Keep the device away from water, re, humidity or hot environments.
Do not attempt to disassemble, repair, or modify the device. If you need service, please
contact us.
Do not use the device where wireless devices are not allowed.
The socket-outlet shall be installed near the equipment and shall be easily accessible.
For passthrough devices, plug the power strips into the integrated electrical sockets
of the devices, but devices of the same or another type not be stacked in normal use.
Do not plug in a row.
TP-Link hereby declares that the device is in compliance with the essential requirements and
other relevant provisions of directives 2014/53/EU, 2009/125/EC, 2011/65/EU and (EU)2015/863.
The original EU declaration of conformity may be found at https://www.tp-link.com/en/ce.
For technical support, replacement services, user guides, and
other information, please visit https://www.tp-link.com/support,
or simply scan the QR code.
If you have any suggestions or needs for our product guides, you
are welcome to email techwriter@tp-link.com.cn.
To communicate with TP-Link users or engineers, please join the
TP-Link Community at https://community.tp-link.com.
Method 2: Via a Web Browser
1. Connect your computer or smartphone to the extender’s network . If you are
using a computer, unplug the Ethernet cable if any.
2. Launch a web browser, enter http://tplinkrepeater.net in the address bar, and
log in.
3. View or change extender settings as needed.
Method 1: Via the Tether App
1. Connect your smartphone to the extender‘s or router’s network.
2. Launch the Tether app, select your extender, and log in.
3. View or change extender settings as needed.
Access Extender Settings
After setup, you can access extender settings via any of the methods below.
You can reselect host network, change extended network settings and more.
Note: If your extender and router use the same network name, Method 1 is recommended.
The Ethernet port is connected or not connected to
a powered-on device.
Tether
http://tplinkrepeater.net
http://tplinkrepeater.net

TP-Link RE365 Specifications

General

Maximum data transfer rate	1200 Mbit/s
Ethernet LAN (RJ-45) ports	1
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Ethernet LAN	Yes
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2-PSK
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Wi-Fi data rate (max)	867 Mbit/s
Ethernet LAN data rates	10, 100 Mbit/s
Product type	Network repeater
Product color	White
Antenna type	Internal
Antennas quantity	2
Frequency band	2.4/5 GHz
Signal strength	19 dBm
Receiver sensitivity	5GHz: 11a 6Mbps: -92dBm, 11a 54Mbps: -74dBm 11ac HT20: -72dBm, 11ac HT40: -63dBm 11ac HT80: -59dBm 2.4GHz: 11g 54Mbps: -75dBm, 11n HT20: -73dBm 11n HT40: -70dBm
Certification	CE, RoHS
Browser supported	Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0
Maximum transfer distance	3048 m
Windows operating systems supported	Windows 10, Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows NT, Windows Vista, Windows XP
Sustainability certificates	RoHS
Power consumption (typical)	8 W
Package type	Box
Package depth	104 mm
Package width	171 mm
Package height	99 mm
Package weight	370 g
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	70 mm
Width	125 mm
Height	77 mm
Dimensions (WxDxH)	70 x 77 x 125 mm
