2
II. Specifications
Electrical Specifications
Model TL-ANT5830B
Frequency Rang-MHz 5150-5850
Gain-dBi 30
VSWR ≤1.8
Horizontal Beamwidth-° 6
Vertical Beamwidth-° 4
Polarization Vertical or Horizontal
F/B Ratio-dB ＞30
Impedance-Ω 50
Maximum Input Power-W 100
Connector N Female
Mechanical Specifications
Antenna Dimension-mm 600×900
Weight-Kg 3, 5
Mounting Mast Diameter-mm Ø30～Ø50
Radome Material Aluminium Die Cast
Rated Wind Velocity-Km/h 241
