Trane 4MCW3-A User Manual

1234-TTT000-EN 15
Note: For additional information on maximum piping length for these systems, please refer to
Application guide 32-3009-03.
Connection Pipe
13 SEER (60 Hz)
4MCW3509A1AA
4TTK3509A1AA
4MCW3512A1AA
4TTK3512A1AA
4MCW3518B1AA
4TTK3518B1AA
4MCW3524B1AA
4TTK3524B1AA
Refrigerant Charge (lbs)
2.2 (R-410A) 2.3 (R-410A) 4.84 (R-410A) 5.07 (R-410A)
Length (m)
8888
Gas additional charge (g/m)
30 30 40 40
Connection
Outer
Diameter
Liquid Pipe (mm)
6 (1/4") 6 (1/4") 9.52 (3/8") 9.52 (3/8")
Pipe Gas Pipe (mm)
12 (1/2") 12 (1/2") 16 (5/8") 16 (5/8")
Max
Distance
Height (m)
5 5 10 10
Length (m)
10 10 15 15

Trane 4MCW3-A Specifications

General

Brand	Trane
Model	4MCW3-A
Category	Air Conditioner
Language	English
