Part 2 4-way Cassette
TRANE Model
IDU 4MXC2309BF0W0AA 4MXC2312BF0W0AA
Panel 4MXL2318BF0W0AA 4MXL2318BF0W0AA
Power supply V-ph-Hz 220-1-50(60) 220-1-50(60)
Cooling
Capacity Btu/h 8,500 12,000
Capacity W 2,500 3,500
Heating
Capacity Btu/h 9,000 12,000
Capacity W 2,700 3,500
Indoor fan
motor
Model ZW465C03 ZW465C03
Qty 1 1
Input w 33 33
Capacitor uF / /
Speed(hi/mi/lo) r/min 690/620/560 690/620/560
Indoor coil
a.Number of rows 1 2
b.Tube pitch(a)× row pitch(b) mm 21×13.3 21×13.3
c.Fin spacing mm 1.25 1.25
d.Fin type (code) Hydrophilic aluminium Hydrophilic aluminium
e.Tube outside dia.and type mm Ф7,innergroove tube Ф7,innergroove tube
f.Coil length × height × width mm 1,330×210×13.3 1,330×210×26.6
g.Number of circuits 5 10
Indoor air ow (Hi/Med/Lo) m 620/520/450 620/520/450
Sound level (sound pressure) dB(A) 36/33/30 36/33/30
Throttle type / /
Indoor unit
Dimension (W × D × H)(body) mm 570×570×260 570×570×260
Packing (W × D × H)(body) mm 718×680×380 718×680×380
Dimension (W × D × H)(panel) mm 620×620×60 620×620×60
Packing (W × D × H)(panel) mm 660×660×115 660×660×115
Net/Gross weight(body) kg 17/20 18.5/22
Net/Gross weight(panel) kg 2.8/4.8 2.8/4.8
Design pressure MPa 4.15 4.15
Drainage water pipe dia. mm PVC 26/32 PVC 26/32
Refrigerant
piping
Liquid side/ Gas side mm Φ6.35/Φ9.52 Φ6.35/Φ9.52
Controller Remote control Remote control
Operation temperature
℃
16~30 16~30
Room
temperature
Cooling
℃
18~32 18~32
Heating
℃
15~27 15~27
Qty’per 20’ /40’ /40'HQ 118/240/284 118/240/284
