Trane 4WCZ6036B3000A User Manual

8
18-BB35D1-16B-EN
Figure 2. Bottom and Back Duct Openings
B
C
D
E
F
E
G
H
M
L
J
J
I
K
N
Height
mm (in)
A B C D E F G H I J K L M N
4WCZ6036
4WCZ6048
4WCZ6060
PHYSICAL DIMENSIONS mm (in)
86.25
(3.39)
449.02
(17.67)
176.07
(6.93)
329.58
(12.97)
372.82
(14.67)
1351.95
(53.22)
176.68
(6.95)
296.62
(11.67)
1155.45
(45.49)
457.20
(18.0)
82.16
(3.23)
82.16
(3.23)
381.00
(15.0)
244.09
(9.61)
325.49
(12.80)
381.00
(15.0)
167.89
(6.61)
173.46
(6.83)
304.80
(12.0)
48.35
(1.90)
398.22
(15.67)
176.07
(6.93)
949.33
(37.37)
1050.93
(41.37)
304.80
(12.0)
92.33
(3.63)
66.51
(2.62)
406.40
(16.0)
W1 W2 W3 W4 BB CC
4WCZ6036 60.8 [134] 38.1 [84] 27.2 [60] 42.6 [94] 200.5 [442] 168.7 [372] 401.3 [15.8] 508 [20]
4WCZ6048 68.9 [152] 40.8 [90] 30.8 [68] 52.2 [115] 275.6 [607] 217.5 [479] 414.0 [16.3] 635 [25]
4WCZ6060 80.3 [177] 47.6 [105] 35.8 [79] 60.8 [134] 282.8 [623] 224.5 [495] 414.0 [16.3] 635 [25]
Corner Weights KG/LBS
SHIPPING WEIGHT
KG/LBS
UNIT WEIGHT
KG/LBS
Center Of Gravity mm[inch]
457.20
(18.0)
DDeetteerrmmiinnee UUnniitt CClleeaarraanncceess
