Trane A952V040BU3SAB User Manual

88-A952V001-1D-EN
97
Integrated Furnace Control Menu
CLEARING THE LAST6 FAULTS: To clear the stored faults, scroll to the last 6 faults menu, enter the menu by scrolling to the right and hold the “Op!on” key for at least 5 seconds. Release and a set of 3 dashes will be seen 3 !mes. This confirms the faults have been cleared
SETTING UP YOUR SYSTEM: To change any factory default value, first remove any “call” from the furnace and allow any fan off delays to finish. ( should be seen on the display) Scroll to the selected Menu item by momentarily depressing the “MENU” key and then depress the “OPTION” key to the desired se$ng. Then momentarily depress the “MENU” key again to save the change.
CFM per Ton selec!ons range from 290 – 450 Important: When applied with zoning or a VSPD outdoor unit,
the CFM/Ton must be set to 400
Gas Hea!ng CFM shown is 2
nd
stage airflow. 1
st
stage
airflow is ~80% of the selected 2
nd
stage airflow and
cannot be adjusted.
Gas hea!ng CFM can be adjusted while the unit is opera!ng in gas heat mode to enable the technician to
quickly adjust to the manufacturer's suggested heat rise across the heat exchanger. Mulply the value shown by 10 for actual airflow
Model Gas Heang CFM [ ]=Default Upflow A952V040BU3SAB 088 [088], 140, 065, 083 A952V060BU3SAB 103 [103], 113, 130, 080 A952V060BU4SAB 116 [116], 130, 099, 109 A952V080BU4SAB 126 [126], 133, 146, 120 A952V080CU5SAB 145 [145], 156, 208, 119 A952V100CU4SAB 183 [183], 145, 162, 172 A952V100CU5SAB 206 [206], 215, 159, 198 A952V120DU5SAB 195 [195], 225, 156, 185 Downflow A952V040BD3SAB 088 [088], 095, 125, 065 A952V060BD3SAB 103 [103], 113, 080, 090 A952V080BD4SAB 126 [126], 133, 148, 120 A952V100CD4SAB 183 [183], 189, 150, 162 A952V100CD5SAB 210 [210], 152, 180, 187 A952V120DD5SAB 225 [225], 175, 185, 195
Model ODT Opons [ ]= Default Upflow
A952V040BU3SAB 3T[3T], 1.5T, 2T, 2.5T A952V060BU3SAB 3T[3T], 1.5T, 2T, 2.5T A952V060BU4SAB 4T[4T], 2.5T, 3T, 3.5T A952V080BU4SAB 4T[4T], 2.5T, 3T, 3.5T A952V080CU5SAB 5T[5T], 3.5T, 4T, 4.5T
A952V100CU4SAB 4T[4T], 2.5T, 3T, 3.5T A952V100CU5SAB 5T[5T], 3.5T, 4T, 4.5T A952V120DU5SAB 5T[5T], 3.5T, 4T, 4.5T
Downflow A952V040BD3SAB 3T[3T], 1.5T, 2T, 2.5T
A952V060BD3SAB 3T[3T], 1.5T, 2T, 2.5T A952V080BD4SAB 4T[4T], 2.5T, 3T, 3.5T A952V100CD4SAB 4T[4T], 2.5T, 3T, 3.5T
A952V100CD5SAB 5T[5T], 3.5T, 4T, 4.5T A952V120DD5SAB 5T[5T], 3.5T, 4T, 4.5T
IdL
STATUS MENU
Err
ACTIVE ERRORS
Ht1 Arf
Example
1
st
stage Gas Heat
Example
800 CFM
E3.4
Example
2
nd
Stage Pressure
Switch Error
E3.1
Example
1st Stage Pressure
Switch Error
L6F
LAST 6 FAULTS
E3.4 E3.1 E04
Example
2
nd
Stage Pressure
Switch Error
Example
1st Stage Pressure
Switch Error
Example
Open Limit Switch
Error
CR1
Control Release#
CR21
Example
So+ware Version #
COd
Cooing Off Delay
000 090 180 EH
Example
seconds
Example
Enhanced Mode
ODT
OD Tonnage
3.0
Example
OD Nominal Tonnage
2.0 2.5 3.5
ODU
OD Unit Type
1-1 2-1
Example
Single Stage
COF
Con!nuous Fan
050 025
Example
50% Cooling Airflow
CPC
Cooliing CFM
per Ton
350 390
450
Example
CFM per Ton
100 60
100 140
HOD
Heat Off Delay
Example
Seconds
600 000
300 900
ISD
Inter-Stage Delay
Example
Seconds
103 113
146 083
G
HC
Gas Hea!ng CFM
Example
2
nd
stage Hea!ng CFM
A952V
Control System Menu
2-2
Example
2 stage 1 compressor
Example
2 stage 2 compressor
080
CPH
Hea!ng CFM
per Ton
350 390
450
Example
CFM per Ton
rUn
Run Test Mode
See Run Test Menu
