Trane CGCL 200 User Manual

6 CGCL-SVX01B-E4
General unit characteristics
Table 1 - CGCL general data
CGCL 200 CGCL 250 CGCL 300 CGCL 350 CGCL 400 CGCL 450 CGCL 500 CGCL 600
R407C R407C R407C R407C R407C R407C R407C R407C
Eurovent Performances (1)
Net cooling capacity (kW) 49.2 61.1 74.0 86.9 101.0 111.0 126.0 152.0
Total power input in cooling (kW) 21.9 26.9 34.6 38.3 46.8 55.5 59.7 73.1
Evaporator water pressure drop (kPa) 42 41 42 41 39 46 56 68
Main power supply 400/3/50
Sound power level 300 Pa (dB(A)) 88 84 87 89 91 95 90 94
Sound power level 400 Pa (dB(A)) 90 86 89 90 93 96 92 95
Sound power level 500 Pa (dB(A)) 91 88 90 92 94 97 93 96
Units Amps
Nominal (4) (A) 48 61.4 76.7 86.1 102.3 117.7 120.8 151.3
Start-up amps (A) 150 209 224 234 250 265 268 299
Recommended fuse size (Am) (A) Depends on installation
Max supply cable size (mm
2
)3535505095959595
Max. wire length (m) Depends on installation
Compressor
Number (circ 1/ circ 2) 2223332/22/2
Type Scroll
Model 10T+10T 10T+15T 2x15T 2x10T+15T 10T+2x15T 3x15T 2x(10T+15T) 4x15T
Number of speeds 11111111
Number of motors 11111111
Rated amps (2)(4) (A) 37 46 55 65 74 83 92 110
Locked rotor amps (2) (A) 139 194 203 212 221 230 240 258
Motor RPM (rpm) 2900 2900 2900 2900 2900 2900 2900 2900
Sump heater (2) (W) --------
Evaporator
Number 1
Type Brazed plate
Water volume (total) (l) 4.7 5.9 7.0 8.2 10.5 10.5 12.3 16.1
Antifreeze Heater (W) 65 65 65 65 65 65 130 130
Water connection type Male ISO R7
Water connection diameter 1"1/2 1"1/2 1"1/2 2" 2" 2" 2"1/2 2"1/2
Coil
Type Plate Fin
Tube size (mm) 9.52
Tube type Smooth
Height (mm) 914 1219 1219 1219 1219 1219 1626 1626
Length (mm) 1829 1829 1829 2743 2743 2743 2743 2743
Face Area (m
2
)1.672.232.233.343.343.344.464.46
Number of rows 4
Fins per inch (fpf) 180
Fan
Type Centrifugal
Number 12222233
Diameter AT 18-18
Drive type Belt Drive
Number of speeds 2
Number of motors 1
Dimensions
Height (mm) 1997 1997 1997 1997 1997 1997 1997 1997
Length (mm) 2268 2268 2268 3230 3230 3230 3230 3230
Width (mm) 866 866 866 866 866 866 1216 1216
Weight uncrated (kg) 710 830 890 1080 1140 1200 1380 1500
Weight crated (kg) 750 870 930 1130 1190 1250 1450 1570
Refrigerant circuit data
Number of circuits 11111122
Refrigerant charge A/B (kg) 12/- 15/- 15/- 24/- 24/- 24/- 15/15 15/15
Oil charge A/B (l) 7.6/- 10/- 12.4/- 13.8/- 16.2/- 18.6/- 10/10 12.4/12.4
(1) at Eurovent Conditions at nominal airflow (Evap 12°C/7°C - Air. 35°C)
(2) per motor
(3) per circuit
(4) 5°C saturated suction temperature - 60°C saturated discharge temperature
