UNT-SVX07A-EN 11
Installation
dimensions
& weights
Vertical Cabinet Unit Dimensions, in-lbs.
unit
size 02-03 04 06 08 10-12
A 2’-9
5
/16” 3’-2
5
/16” 3’-11
3
/16” 4’-8
5
/16” 6’-3
5
/16”
B 1’-9
5
/16” 2’-2
5
/16” 2’-11
3
/16” 3’-8
5
/16” 5’-3
5
/16”
C7
5
/8”7
1
/8”8
7
/8”7
1
/8”7
5
/8”
D 1’-6” 2’-0” 2’-6” 3’-6” 5’-0”
E 1’-7
5
/16” 2’-0
5
/16” 2’-9
13
/16” 3’-6
5
/16” 5’-1
5
/16”
F 3’-5
5
/16” 3’-10
5
/16” 4’-7
3
/16” 5’-4
5
/16” 6’-11
5
/16”
operating weight 97 125 155 164 218
shipping weight 84 112 139 148 200
Notes:
1. Coil connections are always on the drain pan side and opposite the control box.
2. Coil connections are
5
/8” O.D. sweat. See pages 21-22 for locations.
3. All duct collar dimensions are to the outside of the collar.
4. See pages 23-24 for fresh air opening dimensions.
Vertical Cabinet, Model B
