S8XB-SF-2B-EN
15
Airflow Tables
Furnace Airflow (CFM) Vs. External Static Pressure (in. W.C.)
Model
Tap
0.1 0.3 0.5 0.7 0.9
S8B1B080M4PSBA
S8X1B080M4PSBA
S8X2B080M4PSBA
1 633 297 — — —
2 957 800 719 428 213
3 1220 1080 940 800 660
4 1403 1298 1192 1087 981
5 1524 1428 1336 1248 1164
6 1684 1574 1544 1401 1337
7 1700 1625 1551 1476 1401
8 1858 1790 1723 1656 1589
9 1967 1898 1829 1760 1691
Furnace Airflow (CFM) Vs. External Static Pressure (in. W.C.)
Model
Tap
0.1 0.3 0.5 0.7 0.9
S8B1D120M5PSBA
S8X1D120M5PSBA
S8X2D120M5PSBA
1 748 540 328 114 —
2 1192 1003 812 617 420
3 1559 1389 1217 1041 862
4 1944 1798 1649 1497 1342
5 2117 1984 1847 1708 1565
6 2234 2111 1985 1855 1723
7 2377 2267 2155 2040 1921
8 2516 2426 2332 2235 2135
9 2571 2490 2406 2319 2229
To Next Page
