S8XB-SVX001-1A-EN
29
Table 5. High Altitude Kit
Furnace Models Kit Model No. PS1-LOW SET PT PS2-HIGH SET PT
S8*1A026M2P* BAYSWT20AHALTAA NA
-0.25" +/- 0.05" WC
S8*1A040M3P* BAYSWT21AHALTAA NA
-0.47" +/- 0.05" WC
S8*1B040M2P* BAYSWT21AHALTAA NA
-0.47" +/- 0.05" WC
S8*1B060M4P* BAYSWT15AHALTAA NA
-0.60" +/- 0.05" WC
S8*1B080M4P* BAYSWT15AHALTAA NA
-0.60" +/- 0.05" WC
S8*1C080M5P* BAYSWT14AHALTAB NA
-0.50" +/- 0.05" WC
S8*1C100M5P* BAYSWT14AHALTAB NA
-0.50" +/- 0.05" WC
S8*1D120M5P* BAYSWT14AHALTAB NA
-0.50" +/- 0.05" WC
S8X2A040M3P* BAYSWT22AHALTAA
-0.25" +/- 0.05" WC -0.47" +/- 0.05" WC
S8X2B060M4PSAAA BAYSWT17AHALTAA
-0.30" +/- 0.05" WC -0.60" +/- 0.05" WC
S8X2B060M4PSAAB & later BAYSWT23AHALTAA
-0.40" +/- 0.05" WC -0.70" +/- 0.05" WC
S8X2B060M4PTAAA & later BAYSWT23AHALTAA
-0.40" +/- 0.05" WC -0.70" +/- 0.05" WC
S8X2B080M4P* BAYSWT18AHALTAA
-0.37" +/- 0.05" WC -0.60" +/- 0.05" WC
S8X2C080M5P* BAYSWT16AHALTAB
-0.25" +/- 0.05" WC -0.50" +/- 0.05" WC
S8X2C100M5P* BAYSWT19AHALTAA
-0.37" +/- 0.05" WC -0.50" +/- 0.05" WC
S8X2D120M5P* BAYSWT24AHALTAA
0.45" +/ 0.05"WC -0.50" +/- 0.05" WC
General Venting
VENT PIPING
These furnaces have been classified as Fan-Assisted
Combustion System, Category I furnaces under the
"latest edition" provisions of ANSI Z21.47 standards.
Category I furnaces operate with a non-positive vent
static pressure and with a flue loss of not less than 17
percent.
Multistory and common venting are permitted for
these furnaces. Venting systems shall be in accordance
with the National Fuel Gas Code, ANSI Z223.1/NFPA 54,
local codes, and this installation manual.
If desired, a side wall termination can be accomplished
through the use of a listed "add-on" draft inducer. The
inducer must be installed according to the inducer
manufacturer’s instructions. Set the barometric
pressure relief to achieve –0.02 inch water column.
The furnace shall be connected to a factory built
chimney or vent complying with a recognized standard,
or a masonry or concrete chimney lined with a lining
material acceptable to the authority having jurisdiction.
VENTING INTO A MASONRY CHIMNEY
If the chimney is oversized, the liner is inadequate, or flue-gas
condensation is a problem in your area, consider using the chimney as
a pathway or chase for type "B" vent or flexible vent liner. If flexible
liner material is used, size the vent using the "B" vent tables, then
reduce the maximum capacity by 20% (multiply 0.80 times the
maximum capacity). Masonry Chimney Kit BAYVENT800B may be
used with these furnaces (Upflow model furnaces only) to allow
venting into a masonry chimney. Refer to the BAYVENT800B
Installer’s Guide for application requirements.
INTERNAL MASONRY CHIMNEYS
Venting of fan assisted appliances into a lined, internal masonry
chimney is allowed only if it is common vented with at least one
natural draft appliance; OR, if the chimney is lined with type "B",
double wall vent or suitable flexible liner material
WWAARRNNIINNGG
SSaaffeettyy HHaazzaarrdd!!
FFaaiilluurree ttoo ffoollllooww tthhiiss wwaarrnniinngg ccoouulldd rreessuulltt iinn ccaarrbboonn
mmoonnooxxiiddee ppooiissoonniinngg oorr ddeeaatthh..
TThhee cchhiimmnneeyy lliinneerr mmuusstt bbee tthhoorroouugghhllyy iinnssppeecctteedd ttoo
iinnssuurree nnoo ccrraacckkss oorr ootthheerr ppootteennttiiaall aarreeaass ffoorr fflluuee ggaass
lleeaakkss aarree pprreesseenntt iinn tthhee lliinneerr.. LLiinneerr lleeaakkss wwiillll rreessuulltt
iinn eeaarrllyy ddeetteerriioorraattiioonn ooff tthhee cchhiimmnneeyy..
The following section does not apply if BAYVENT800B (Masonry Chimney Vent Kit) is used. All instructions with the kit must be
followed.
FFuurrnnaaccee GGeenneerraall IInnssttaallllaattiioonn
