8
18-CE04D1-1D-EN
Accessories
Table 1. Accessories
Model Number Description Use with
BAYHANG Horizontal Hanging Kit All Furnaces
BAYLIFTB Dual Return Kit (B size extension) B Cabinet Furnaces
BAYLIFTC Dual Return Kit (C size extension) C Cabinet Furnaces
BAYLIFTD Dual Return Kit (D size extension) D Cabinet Furnaces
BAYBASE205 Downflow Subbase All Furnaces in Downflow orientation
BAYSF1165AA
(a)
1” SlimFit Box with MERV 4 Filter All Furnaces
BAYSF1255BA 1” SlimFit Filter and Insulated Frame All furnaces when used in side return
application
B Cabinet furnaces only when in bottom return
application
FLRSF1255 1” Filter replacement (Qty 12) BAYSF1255BA
BAYVENT600A Internal venting kit B, C, and D Furnaces in Downflow orientation
BAYVENT800B Masonry Chimney Vent Kit All furnaces
BAYSWT20AHALTAA High Altitude Pressure Switch Kit S8X1A026M2P*
BAYSWT21AHALTAA High Altitude Pressure Switch Kit S8X1A040M3P*, S8X1B040M2P*
BAYSWT22AHALTAA High Altitude Pressure Switch Kit S8X2A040M3P*
BAYSWT14AHALTAB High Altitude Pressure Switch Kit S8X1C080M5P*, S8X1C100M5P*,
S8X1D120M5P*
BAYSWT15AHALTAA High Altitude Pressure Switch Kit S8X1B060M3P*, S8X1B060M4P*,
S8X1B080M4P*
BAYSWT16AHALTAB High Altitude Pressure Switch Kit S8X2C080M5P*
BAYSWT17AHALTAA High Altitude Pressure Switch Kit S8X2B060M3PSAAA, S8X2B060M4PSAAA
BAYSWT18AHALTAA High Altitude Pressure Switch Kit S8X2B080M4P*
BAYSWT19AHALTAA High Altitude Pressure Switch Kit S8X2C100M5P*
BAYSWT23AHALTAA High Altitude Pressure Switch Kit S8X2B060M3PSAAB & later,
S8X2B060M3PTAAA & later,
S8X2B060M4PSAAB & later,
S8X2B060M4PTAAA & later
BAYSWT24AHALTAA High Altitude Pressure Switch Kit S8X2D120M5P*
BAYLPSS400* Propane Conversion Kit with Stainless Steel
Burners
All Furnaces except S8X1A026
BAYLPSS410A
Propane Conversion Kit with Stainless Steel
Burners
S8X1A026 Furnace only
PIP02095 U fitting for gas piping All Furnaces for right hand gas entry
(a)
Airflow greater than 1600 CFM requires dual returns
Document Pack Contents
Item Qty. Description
SSAAFFEETTYY WWAARRNNIINNGG
Onlyqualified personnelshould installand servicethe equipment.The installation,starting up,and servicingof heating,ventilating, andair-conditioning
equipmentcan behazardous andrequires specificknowledge andtraining. Improperlyinstalled, adjustedor alteredequipment byan unqualifiedperson
couldresult indeath orserious injury.When workingon theequipment, observeall precautionsin theliterature andon thetags, stickers,and labelsthat
areattached tothe equipment.
May 2020
1188--CCEE0044DD11--11DD--EENN
Upow/Downow/Horizontal
Gas-Fired, 1–Stage and 2–Stage Induced Draft Furnaces with
High Efciency Motor
UUppffllooww,, DDoowwnnffllooww,,HHoorriizzoonnttaall RRiigghhtt//LLeefftt
Single Stage
S8X1A026M2PSAB
S8X1A040M3PSAB
S8X1B040M2PSAB
S8X1B060M3PSAB
S8X1B060M4PSAB
S8X1B080M4PSAB
S8X1C080M5PSAB
S8X1C100M5PSAB
S8X1D120M5PSAB
Two Stage
S8X2A040M3PSAB
S8X2B060M3PSAB
S8X2B060M4PSAB
S8X2B080M4PSAB
S8X2C080M5PSAB
S8X2C100M5PSAB
S8X2D120M5PSAB
S8X1
S8X2
NNoottee::This installer’s Guide isused formultiple furnace families. Models
may have a“T” in the 12th digit designating they meet California less
than 40ng/J (NOx) emissions requirements.
NNoottee::Graphics inthis document are for
representation only. Actual model may
differ inappearance.
18-CE04D1-1D-EN
Installer’s Guide
1 1 Plug — Gas
2 1 Installer’s Guide
3 1 Service Facts
4 1 Owner Guide
5 1 Limited Warranty
6 2 Tinnerman Clips
Note: Tinnerman Clips should be
kept with unit and are used
if the door panel flange hole
(s) becomes stripped.
