Trane TTA120C series User Manual

10
TTA-SVX02C-EN
Table 3 - TTA Unit Electrical Data
Compressor Motor
Allowable Minimum Maximum
Model Electrical Voltage Circuit Fuse Amps Amps
Number Characteristic
s
Range Ampacity Size Qty. RLA LRA Qty. HP FLA LRA
TTA090A3 208-230/60/3 187-254 34.5 50 1 25.1 182.0 1 1/2 3.1 8.1
TTA090A4 460/60/3 414-506 18.1 25 1 13.2 94.9 1 1/2 1.6 3.7
TTA090AK 380/60/3 342-418 21.0 30 1 15.0 106.3 1 1 2.2 5.8
TTA090AW 575/60/3 518-632 14.5 20 1 10.6 70.0 1 1/2 1.2 3.0
TTA075AD 380-415/50/3 380-415 15.6 25 1 11.2 94.9 1 1/2 1.6 4.0
TTA085AD 380-415/50/3 380-415 19.1 25 1 13.1 100.0 1 1 2.7 9.3
TTA120A3 208-230/60/3 187-254 48.1 70 1 33.7 278.0 1 1 6.0 17.0
TTA120A4 460/60/3 414-506 23.3 35 1 16.5 124.0 1 1 2.7 7.0
TTA120AK 380/60/3 342-418 26.0 40 1 18.1 137.0 1 1 3.4 7.8
TTA120AW 575/60/3 518-632 18.8 25 1 13.4 92.0 1 1 2.0 5.7
TTA100AD 380-415/50/3 380-415 22.5 35 1 15.8 124.0 1 1 2.7 9.3
TTA120B3 208-230/60/3 187-254 47.9 60 2 18.6 128.0 1 1 6.0 17.0
TTA120B4 460/60/3 414-506 23.9 30 2 9.4 63.0 1 1 2.7 7.0
TTA120BK 380/60/3 342-418 27.5 35 2 10.7 64.0 1 1 3.4 7.8
TTA120BW 575/60/3 518-632 19.1 25 2 7.6 49.0 1 1 2.0 5.7
TTA100BD 380-415/50/3 380-415 23.9 30 2 9.4 63.0 1 1 2.7 9.3
TTA150B3 208-230/60/3 187-254 55.5 70 2 22.0 156.0 1 1 6.0 17.0
TTA150B4 460/60/3 414-506 25.2 35 2 10.0 70.0 1 1 2.7 7.0
TTA150BK 380/60/3 342-418 27.5 35 2 10.7 70.0 1 1 3.4 7.8
TTA150BW 575/60/3 518-632 20.5 25 2 8.2 54.0 1 1 2.0 5.7
TTA125BD 380-415/50/3 380-415 25.2 35 2 10.0 70.0 1 1 2.7 9.3
TTA180B3 208-230/60/3 187-254 62.7 80 2 25.1 182.0 2 1/2 3.1 8.1
TTA180B4 460/60/3 414-506 32.9 45 2 13.2 94.9 2 1/2 1.6 3.7
TTA180BK 380/60/3 342-418 38.2 50 2 15.0 106.3 2 1 2.2 5.8
TTA180BW 575/60/3 518-632 26.3 35 2 10.6 70.0 2 1/2 1.2 3.0
TTA155BD 380-415/50/3 380-415 28.4 35 2 11.2 94.9 2 1/2 1.6 4.0
TTA240B3 208-230/60/3 187-254 87.8 100 2 33.7 278.0 2 1 6.0 17.0
TTA240B4 460/60/3 414-506 42.5 50 2 16.5 124.0 2 1 2.7 7.0
TTA240BK 380/60/3 342-418 47.5 60 2 18.1 137.0 2 1 3.7 7.8
TTA240BW 575/60/3 518-632 34.2 45 2 13.4 92.0 2 1 2.0 5.7
TTA200BD 380-415/50/3 380-415 41.0 50 2 15.8 124.0 2 1 2.7 9.3
TTA120C3 208-230/60/3 187-254 49.4 60 2 17.7 123.0 1 1 6.0 17.0
TTA120C4 460/60/3 414-506 25.2 30 2 9.0 62.0 1 1 2.7 7.0
TTA120CW 575/60/3 518-632 19.8 25 2 7.9 50.0 1 1 2.0 5.7
TTA120CD 380-415/50/3 380-415 24.4 30 2 10.0 58.0 1 1 1.9 5.8
TTA180C3 208-230/60/3 187-254 62.7 80 2 25.1 182.0 2 1/2 3.1 8.1
TTA180C4 460/60/3 414-506 32.9 45 2 13.2 94.9 2 1/2 1.6 3.8
TTA180CW 575/60/3 518-632 26.3 35 2 10.6 70.0 2 1/2 1.2 3.0
TTA155CD 380-415/50/3 380-415 28.4 35 2 11.2 94.9 2 1/2 1.6 4.0
Outdoor Fan Motor Basic Unit Characteristics
Electrical Data
