５
INSTALLATION INSTRUCTIONS
STEP 1: (Selecting Site) Before installing your new lift, check the following:
1. LIFT LOCATION: Always use architects plans when available. Check layout dimension against floor plan
requirements making sure that adequate space is available (Fig. 2 & Fig. 3). Place 102 inch long plate on
floor and push posts against plate to get correct width.
Fig. 2
Fig. 3
138"
102" length of plate on floor
100" between the bases
Call 866-563-5438 For Help
