Triumph Speed Triple 1200 RS User Manual

Maintenance
148
Warning
Draining or extraction of fuel from a
fuel tank must be carried out in a well
ventilated area.
The receptacle used to contain the
fuel must be more than adequate for
the full amount of fuel to be extracted
or drained. The receptacle should be
clearly marked with its contents, and
placed in a safe storage area which
meets the requirements of local
authority regulations.
When fuel has been extracted
or drained from a fuel tank, the
precautions governing naked lights
and ignition sources should be
maintained.
Failure to observe any of the above
warnings could bring about a safety
hazard leading to a risk of personal
injury.
To raise the fuel tank:
• Remove the passenger seat/seat
cowl, see page 76.
• Remove the rider seat, see page 77.
• Remove the battery, see page 140.
• Using proprietary professional
automotive workshop equipment
approved for fuel handling, drain the
fuel from the fuel tank.
• Remove the front fixings from both
sides of the rear bracket.
• Loosen but do not fully remove the
rear fixings from both sides of the
rear bracket.
B01273
432
1
1. Rear bracket front fixing (left hand
shown)
2. Rear bracket rear fixing (left hand shown)
3. Stop screw (left hand shown)
4. Rear bracket
• Remove the fixings from the front
bracket.
B01272
2
1
1. Fuel tank
2. Fixings
• With the aid of an assistant, tilt the
fuel tank rearward to gain access
to the underside and the front fuse
box.

Triumph Speed Triple 1200 RS Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, inline 3-cylinder
Engine Capacity	1160 cc
Bore x Stroke	90.0 x 60.8 mm
Compression Ratio	13.2:1
Max Torque	125 Nm @ 9, 000 rpm
Fuel System	Multipoint sequential electronic fuel injection with electronic throttle control
Final Drive	X-ring chain
Transmission	6-speed
Front Wheel	Cast aluminium alloy 17 x 3.5 in
Rear Wheel	Cast aluminium alloy 17 x 6.0 in
Front Tyre	120/70 ZR 17
Rear Tyre	190/55 ZR 17
Length	2090 mm
Seat Height	830 mm
Wheelbase	1445 mm
Rake	23.9°
Dry Weight	198 kg
Fuel Tank Capacity	15.5 litres
Max Power	180 PS (177.5 bhp) (132.4 kW) @ 10, 750 rpm
Exhaust	Stainless steel 3 into 1 header system, side mounted stainless steel silencer
Clutch	Wet, multi-plate
Frame	Aluminium twin spar
Swingarm	Single-sided, cast aluminium
Front Suspension	Ohlins 43 mm USD forks, fully adjustable
Rear Suspension	Ohlins RSU, fully adjustable
Front Brakes	Twin 320 mm discs, Brembo Stylema 4-piston radial monobloc calipers, OC-ABS
Rear Brakes	Single 220 mm disc, Brembo 2-piston caliper, OC-ABS
Instrument Display	5" TFT instrument pack
Width (Handlebars)	792 mm
Height Without Mirrors	1089 mm
Trail	104.7 mm
