Trojan SHAPE 210 User Manual

7
PARTS LIST
No. Description Qty
1 Main Frame 1
2 Handlebar (Ø25 x 1.5) 1
3 Handlebar Post (Ø50 x 1.5) 1
4 Rear Stabiliser (Ø50 x 1.5) 1
5 Flywheel (Ø230, 4 kg) 1
6 Front Stabiliser (Ø50 x 1.5) 1
7 Tension Control Knob 1
8 Round Knob (M16) 1
9 Belt (320/J6) 1
10 Console 1
11 Nut (M10 x 1) 2
12 Bushing (Ø50 x 1.5) 1
13 Left Cover 1
14 Right Cover 1
15 Screw (ST2.9 x 10) 2
16 Ring II 1
17 Axle Sleeve (15/16”) 1
18 Nut (7/8”) 1
19 Belt Pulley with Crank (240J6) 1
20 Left Foot Pedal (YH-30X) 1
21 Right Foot Pedal (YH-30X) 1
22 Axle Bush 2
23 Ball Bearing 2
24 Bolt (M8 x 15 S6) 6
25 Seat Post 1
26 Sensor with Wire (L = 450 mm) 1
No. Description Qty
27 Seat Cushion (DD - 982AT) 1
28 Front Stabiliser End Cap (Ø50) 2
29 Rear Stabiliser End Cap (Ø50) 2
30 U Bracket 2
31 Adjustable Bolt (M6 x 36) 2
32 Hex Nut (M6) 2
33 Spring Washer (Ø6) 2
34 Cap Nut (M10) 4
35 Bolt (M10 x 57) 4
36 Big Curved Washer (Ø10) 4
37 Curved Washer (Ø20 x Ø8 x 1.5) 4
38 Washer (Ø8) 3
39 Bolt (M8 x 10) 1
40
Pan Head Phillips Self Tapping Screw
(ST4.2 x 25)
6
41
Pan Head Phillips Self Drilling Screw
(ST4.2 x 25)
4
42 Locknut (M8) 3
43 Bolt (M8 x 30) 1
44 Pressing Belt Wheel 1
45 Bearing (6000 zz) 2
46 Big Curved Washer (Ø5 x 1.5) 1
47 Bolt (M5 x 10) 2
48 Washer (Ø40 x Ø24 x 3.0) 1
49 Handlebar End Cap (Ø25) 2
50 Handlebar Foam Grip (Ø30 x Ø24 x 455) 2
51 Screw (ST4.2 x 20) 2
52 Screw (M6 x 10) 1
