SECTION 4: KNOW YOUR LAWN TRACTOR
Figure 4
A PTO (Power Take-off) Lever H Cruise Control Button
B Choke Control I Ignition Switch
C Parking Brake Button J Brake Pedal
D Shift Lever K Drive Pedal
E Cup Holder L Cargo Net (not shown)
F Systems Indicator Monitor/ Hour Meter M Deck Lift Lever
G Throttle Control Lever
I
B*
A
H
C
D
E
L
K
J
NOTE: Steering Wheel not shown for clarity.
1
/
1
0
+
P
G
F
M
