7
OPERATING INSTRUCTIONS
1. Use the blower for trees, shrubs, flower beds and hard-to
clean areas. (Fig. 13).
Fig. 12
(A)
(B) (C)
WARNING:
To avoid serious personal injury, wear
goggles or safety glasses at all times when operating
this unit. Wear a face mask or dust mask in dusty
locations.
Fig. 13
Fig. 14
OPERATING AS A VACUUM
WARNING:
Turn off and unplug the unit before
opening vacuum door or installing or removing vacuum
bag to avoid personal injury from the impeller.
SHOULDER STRAP ADJUSTMENTS
1. With the unit turned off, hold the unit in your left hand in an
upright position. Support the lower vacuum tube on the ground
(Fig. 16).
2. Place the vacuum bag strap over your head and onto your left
shoulder.
3. Extend your right arm toward the rear of the vacuum bag.
Adjust the vacuum bag strap until the vacuum bag/shoulder
strap seam lies between your thumb and index finger.
Fig. 16
WARNING:
To avoid serious personal injury, wear
goggles or safety glasses at all times when operating
this unit. Wear a face mask or dust mask in dusty
locations.
Fig. 15
OPERATING AS A BLOWER
Hold the blower as shown in Figs. 13, 14, or 15 and sweep from
side to side with the concentrator tube several inches above the
ground or floor. Slowly advance, keeping the accumulated pile of
debris in front of you.
Most dry blowing operations are better suited to low speed than
high. Of course, you may choose to use either and you’ll probably
find the high speed better for moving heavier items like large
debris or gravel.
2. Use the blower around buildings and for other normal cleaning
(Fig. 14).
3. Use the blower for walls, overhangs and screens (Fig. 15).
low speed operation, slide the switch up to the first click (A). To
select high speed, slide the switch up to the second click (B). To
turn the unit off, slide the switch all the way down (C).
