TSC TDP-225 Service Manual

TDP-225 Series
Bar Code Printer Service Manual
26
4.2 Print Quality
Problem
Possible Cause
Recovery Procedure
Not Printing
Check if interface cable is well
connected to the interface connector.
Re-connect cable to interface.
The serial port cable pin configuration is
not pin to pin connected.
Please replace the cable with pin to pin
connected.
The serial port setting is not consistent
between host and printer.
Please reset the serial port setting.
The port specified in the Windows driver
is not correct.
Select the correct printer port in the
driver.
The Ethernet IP, subnet mask, gateway
is not configured properly.
Configure the IP, subnet mask and
gateway.
No print on the label
Label loaded not correctly.
Follow the instructions in loading the
media.
Continuous feeding
labels
The printer setting may go wrong.
Please do the initialization and
gap/black mark calibration.
Paper Jam
Gap/black mark sensor sensitivity is not
set properly (sensor sensitivity is not
enough)
Calibrate the gap/black mark sensor.
Make sure label size is set properly.
Set label size exactly as installed paper
in the labeling software or program.
Labels may be stuck inside the printer
mechanism near the sensor area.
Remove the stuck label.
Poor Print Quality
Top cover is not closed properly.
Close the top cover completely and
make sure the right side and left side
levers are latched properly.
Wrong power supply is connected with
printer.
Check if 24V DC output is supplied by
the power supply.
Check if supply is loaded correctly.
Reload the supply.
Check if dust or adhesives are
accumulated on the print head.
Clean the print head.

TSC TDP-225 Specifications

General

Print technology	Direct thermal
Vertical printing	Yes
Maximum resolution	203 x 203 DPI
Maximum print height	2286 mm
Maximum printing width	54 mm
Ethernet LAN	No
USB 2.0 ports quantity	1
Connectivity technology	Wired
Flash memory	4 MB
Certification	FCC, CE, TUV, CUL, UL, CCC, C-Tick
Internal memory	8 MB
Built-in barcodes	1D, 2D, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, EAN128, EAN13, EAN8, Interleaved 2/5, MaxiCode, PDF417, POSTNET, QR Code, UPC-A, UPC-E
Built-in processor	RISC 32-bit
Compatible memory cards	SD
Power requirements	100 - 240
AC adapter output current	2 A
AC adapter output voltage	24 V
Display	LCD
Product color	-
Core diameter	38 mm
Ribbon length	90 m
Media thickness	0.06 - 0.19 mm
Maximum label width	60 mm
Maximum label length	2.286 m
Maximum roll diameter	127 mm
Supported paper width	15 - 60 mm
Maximum media length (imperial)	90 \
Supported paper width (imperial)	0.59 - 2.36 \
LED indicators	Power, Status
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	41 - 104 °F

Weight and Dimensions

Depth	209 mm
Width	109 mm
Height	171 mm
