3.5 External Label Roll Mount Installation (Option)
1. Attach the external roll mount to the printer
2. Open the printer top cover.
3. Feed the paper to the external paper feed opening slot.
4. Feed the paper, printing side face up, then adjust the paper guides to fit the paper width.
5. Close the printer top cover by lifting the top cover to the maximum opening angle then push down the top cover gently.
External Paper Feed Opening
