TSC TTP-2610MT Series Service Manual

27
3.11 Cutter Module Installation (Option)
1. Open the printer right side cover.
2. Remove 2 screws to remove the lower front panel.
3. Plug the cutter mini DIN cable connector into the cutter/peel-off connector. The
triangle mark on the connector must be at the upper side.
4. Use 2 screws to lock the cutter fixing plate onto the front printer.
