TSC TTP-2610MT Series Service Manual

5
Rear View
1. External label entrance chute
2. Power cord socket
3. Power switch
4. Ethernet interface
5. * SD card socket
6. USB interface
7. USB host
8. RS-232C interface
9. GPIO interface (Option)
10. Centronics interface
Note:
The interface picture here is for reference only. Please refer to the product specification
for the interfaces availability.
1
3
2
4
US
B
int
erf
ac
e
7
USB
inte
rfac
e
6
5
8
9
Pr
in
t
h
e
a
d
10
Prin
t
hea
d
